, , , l A {in Techl'nlugy INTEGRATED CIRCUITS DIVISION
High Voltage, Analog & Mixed Signal ICs, Optically Isolated Devices
Product Catalog 2021
IXYS A Littelfuse Technology
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
2
IXYS Integrated Circuits
IXYS Integrated Circuits
IXYS Integrated Circuits, formerly a wholly owned subsidiary of IXYS Corporation, is now part of Littelfuse, Inc. IXYS Integrated Circuits designs, manufactures, and markets a
wide variety of semiconductor devices and is a major provider of optically isolated electronic components.
IXYS Integrated Circuits’ unique mix of high voltage wafer fabrication, isolation barrier expertise, multi-chip packaging experience, and expertise in analog, mixed signal, and
power design, points the way to greater functionality in a smaller footprint at lower cost for your designs.
• IGBT and MOSFET Drivers: High voltage, low-side, and optically isolated IGBT and MOSFET drivers, many of which are AEC-Q100 qualified.
• Solid State Relays (SSR): One of the industry’s broadest lines of optically isolated SSRs, available in a wide selection of configurations, blocking voltages, and load currents.
• Power Market: Power solid state relays; SCR-based AC power switches (zero-cross & rapid turn-on); and N-channel, depletion-mode, field effect transistors (FET).
• Lighting Market: High voltage LED drivers.
• HV Switch Arrays: High voltage isolated analog switch arrays
• High Speed Digital Optical Isolators: High speed optically coupled isolators that pass DC signals, require no refresh clocking, and provide 3750VRMS of galvanic isolation.
• I2C Optically Isolated Bus Repeaters: New high speed repeaters that buffer both I2C signals, require no refresh clocking, and provide 3750VRMS of galvanic isolation.
• Non-volatile Digitally Programmable Capacitors: Provide capacitive offset trimming for capacitance sensitive circuits.
• Telecommunications Market:
LITELINK®: Galvanically isolated, single IC, analogue phone line interface
Phone-line interface and monitoring devices
LCAS: Line Card Access Switch products
Products and Markets
OptoMOS® is a registered trademark of IXYS Integrated Circuits
IXYS Aliflellun Tummy
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900
3
Table of Contents
Note: Drawings and photographs of IXYS Integrated Circuits products shown in this catalog are for illustrative purposes only
and do not necessarily portray accurate physical details, marking, or branding. They exist solely to provide additional useful information.
TABLE OF CONTENTS
MOSFETS
N-CHANNEL DEPLETION MODE MOSFETS ............................................26
HIGH SPEED DIGITAL OPTICAL ISOLATORS
SINGLE-CHANNEL EACH DIRECTION DIGITAL OPTICAL ISOLATOR ..................28
DUAL HIGH SPEED DIGITAL OPTICAL ISOLATOR ........................................28
BIDIRECTIONAL, OPTICALLY ISOLATED I²C BUS REPEATER ..........................29
OPTICALLY ISOLATED I²C BUS REPEATER ................................................30
NON-VOLATILE DIGITALLY PROGRAMMABLE CAPACITORS
DIGITALLY PROGRAMMABLE CAPACITORS ..................................................31
HIGH VOLTAGE LED DRIVERS
HIGH EFFICIENCY, HIGH BRIGHTNESS MAINS-POWERED LED DRIVER .........32
HIGH VOLTAGE, MAINS-POWERED LED DRIVER .......................................33
MULTIFUNCTION PRODUCTS: SSR/OPTOCOUPLERS
GENERAL PURPOSE MULTIFUNCTION PRODUCTS .......................................34
TELECOM MULTIFUNCTION PRODUCTS .....................................................35
TELECOM PRODUCTS
LITELINK™ SILICON DAA PHONE LINE INTERFACE ...............................36
LINE CARD ACCESS SWITCHES (LCAS) .................................................38
VOLTAGE MONITORING & SENSING IC
VOLTAGE MONITOR WITH DETECTORS .....................................................39
PART NUMBER INDEX
NUMERICAL INDEX TO ALL PRODUCT CATALOG DEVICES ...............................4
SOLID STATE RELAYS
1-FORM-A RELAYS (NORMALLY OPEN) .....................................................7
1-FORM-B RELAYS (NORMALLY CLOSED) ...............................................10
MISCELLANEOUS RELAYS ......................................................................11
FAULT PROTECTED SOLID STATE RELAYS
CURRENT LIMITING SSRS WITH VTS & TM ...........................................12
OPTICALLY ISOLATED POWER RELAYS
1-FORM-A POWER RELAYS ..................................................................14
OPTICALLY ISOLATED AC POWER SWITCHES
OPTICALLY ISOLATED AC POWER SWITCHES: LOAD CURRENT ≤1A .............16
OPTICALLY ISOLATED AC POWER SWITCHES: LOAD CURRENT >1A .............17
IGBT & MOSFET GATE DRIVERS
LOW-SIDE GATE DRIVERS ....................................................................18
AEC-Q100 QUALIFIED LOW-SIDE GATE DRIVERS ...................................18
OPTICALLY ISOLATED PHOTOVOLTAIC GATE DRIVERS ..................................19
OPTICALLY ISOLATED LOAD-BIASED GATE DRIVERS ...................................19
570V OPTICALLY ISOLATED LOAD BIASED GATE DRIVER ...........................20
SIC GATE DRIVER
9A LOW-SIDE SIC MOSFET & IGBT GATE DRIVERS ...........................21
HIGH VOLTAGE ISOLATED ANALOG SWITCHES
600V QUAD HIGH VOLTAGE ISOLATED ANALOG SWITCH ARRAY ..................22
320V QUAD HIGH VOLTAGE ISOLATED ANALOG SWITCH ARRAY ..................23
320V DUAL HIGH VOLTAGE HIGH FREQUENCY ANALOG SWITCH .................24
OPTOCOUPLERS
LINEAR OPTOCOUPLERS .......................................................................25
SINGLE OPTOCOUPLER .........................................................................25
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
4
Part Number Index
CPC1001N 25
CPC1002N 11
CPC1004N 11
CPC1006N 7
CPC1008N 7
CPC1009N 7
CPC1010N 7
CPC1014N 7
CPC1016N 7
CPC1017N 7
CPC1018N 7
CPC1019N 7
CPC1020N 7
CPC1025N 7
CPC1030N 7
CPC1035N 7
CPC1106N 10
CPC1114N 10
CPC1117N 10
CPC1125N 10
CPC1130N 10
CPC1135N 10
CPC1150N 10
CPC1225N 7
CPC1230N 7
CPC1231N 10
CPC1330 7
CPC1333 10
CPC1335 7
CPC1390 7
CPC1393 7
CPC1394 7
CPC1510 7, 12
CPC1511 7, 12
CPC1540 7, 12
CPC1560 7, 12
CPC1561B 7, 15
CPC1563 7, 12
CPC1580 19
CPC1590 19
CPC1593 7, 12
CPC1596 20
CPC1705Y 10
CPC1706Y 7
CPC1708J 15
CPC1709J 15
CPC1718J 15
CPC1726Y 7
CPC1727J 15
CPC1777J 15
CPC1779J 15
CPC1786J 15
CPC1788J 15
CPC1906Y 7
CPC1907B 7
CPC1908J 15
CPC1909J 15
CPC1916Y 7
CPC1918J 15
CPC1926Y 7
CPC1927J 15
CPC1943 16
CPC1945G 16
CPC1945Y 16
CPC1961 16
CPC1963 16
CPC1964B 17
CPC1964BX6 17
CPC1965G 16
CPC1965Y 16
CPC1966Y 17
CPC1966B 17
CPC1966BX8 17
CPC1966YX6 17
CPC1966YX8 17
CPC1967J 15
CPC1968J 15
CPC1972 16
CPC1973Y 7
CPC1976 17
CPC1976YX6 17
CPC1977J 15
CPC1978J 15
CPC1979J 15
CPC1981Y 7
CPC1983B 7
CPC1983Y 7
CPC1983YE 8
CPC1984Y 8
CPC1986J 15
CPC1988J 15
CPC1998J 17
CPC2014N 9
CPC2017N 9
CPC2025N 9
CPC2030N 9
CPC2125N 10
CPC2317N 11
CPC2330N 11
CPC2907B 9
CPC3701 26
CPC3703 26
CPC3708 26
CPC3710 26
CPC3714 26
CPC3720 26
CPC3730 26
CPC3902 26
CPC3909 26
CPC3960 26
CPC3980 26
CPC3982 26
CPC40055ST 17
CPC5001 28
CPC5002 28
CPC5602 26
CPC5603 26
CPC5620 36
CPC5621 36
CPC5622 36
CPC5712 39
CPC5902 29
CPC5903 30
CPC5904 29
CPC7512 24
CPC7514 23
CPC7524 22
CPC7695 38
CPC9909 32
FDA215 19
FDA217 19
IAA110 34
IAB110 34
IAD110 34
IBB110 34
ITC117 35
ITC117L 35
ITC135 35
ITC137 35
IX4310T 18
IX4340 18
IX4340NE 18
IX4351NE 21
IX4426 18
IX4427 18
IX4428 18
IXD_602 18
IXD_604 18
IXD_604SI 18
IXD_604SIA 18
IXD_609 18
IXD_609SI 18
IXD_614 18
IXD_614SI 18
IXD_630 18
IXD_630M 18
LAA100 9
LAA100L 9
LAA108 9
LAA110 9
LAA110L 9
LAA120 9
LAA120L 9
LAA125 9
LAA125L 9
LAA127 9
LAA127L 9
LAA710 9
LBA110 11
LBA110L 11
LBA120 11
LBA120L 11
LBA127 11
LBA127L 11
LBA710 11
LBA716 11
LBB110 10
LBB120 10
LBB126 10
LBB127 10
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
PART NUMBER INDEX
IXYS A nellun Tummy
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 5
Part Number Index
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
LCA100 8
LCA100L 8
LCA110 8
LCA110L 8
LCA120 8
LCA120L 8
LCA125 8
LCA125L 8
LCA127 8
LCA127L 8
LCA129 8
LCA182 8
LCA210 11
LCA210L 11
LCA220 11
LCA701 8
LCA710 8
LCA712 8
LCA715 8
LCA717 8
LCB110 10
LCB111 10
LCB120 10
LCB126 10
LCB127 10
LCB710 10
LCB716 10
LCB717 10
LCC110 11
LCC120 11
LOC110 25
LOC111 25
LOC112 25
LOC117 25
MXHV9910 33
NCD2100 31
NCD2400M 31
OAA160 9
OMA160 8
PAA110 9
PAA110L 9
PAA127 9
PAA132 9
PAA140 9
PAA140L 9
PAA150 9
PAA190 9
PAA191 9
PAA193 9
PBA150 11
PBB150 10
PBB190 10
PD1201 16
PD2401 16
PD2601 16
PLA110 8
PLA110L 8
PLA132 8
PLA134 8
PLA140 8
PLA140L 8
PLA143 8
PLA150 8
PLA160 8
PLA170 8
PLA171 8
PLA172P 8
PLA190 8
PLA191 8
PLA192 8
PLA193 8
PLA194 8
PLB150 10
PLB171 10
PLB190 10
PM1204 16
PM1205 16
PM1206 16
PS1201 16
PS2401 16
PS2601 16
TS117 34
TS117L 34
TS118 34
TS120 34
TS190 34
TS190L 34
XAA117 9
XAA170 9
XBB170 10
XCA170 8
XCB170 10
XS170 34
; Fm sop I. a PM 5mm anl KFmS "Ia m M‘ IQ All wavemrms are "no a reslsnve load ‘ w m2 44 :I: OploMOS® \s a egwslered lvademar of IXYS Integrated Cir
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
6For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
Solid State Relays
Features:
• Low drive current
• High reliability
• No EMI/RFI generation
• Arc-free with no snubbing circuits
• AC or DC switching
• Current limiting devices available
• FCC compatible
• Low off-state leakage
Applications:
• Instrumentation
• Multiplexers
• Data acquisition/electronic switching
• Meters (Watt-hour, water, gas)
• Medical equipment
(patient/equipment isolation)
• Security
• Industrial controls
• Telecomm / datacomm
• Replace electromechanical relays
• Replace mechanical switches
• Implement computer control
of electromechanical circuits
Polarity Dependent
± Load
± Load
Polarity Independent
Type BI
Control
Input
Load
Current
Load
Voltage
± Load
Do Not
Use
± Load
Type BI+ (BI)
+ Load
– Load
Type BI+ (UNI)
Load+
Load–
Type UNI
All waveforms are into a resistive load
Control
Input
Load
Current
Load
Voltage
+V
+I
-V
-I
+V
+I
-V
-I
Type BI relays conduct load current in both directions.
Type BI+ relays, in BI configuration, conduct load current in both directions.
Type UNI relays conduct load current from the positive terminal to the negative terminal only.
Type BI+ relays, in UNI configuration with output MOSFETs wired in parallel, enable higher load
current from positive terminal to negative terminal only.
The accompanying SSR tables reference these types (BI, BI+, & UNI) for all devices listed.
Packages are referenced
by number in the following
Solid State Relay
selection tables
SOLID STATE RELAYS
10
4-Pin SOP
12
6-Pin Surface Mount
14
6-Pin DIP
6-Pin DIP
17
8-Pin SOP
21
8-Pin Flatpack
22
8-Pin Surface Mount
20
8-Pin DIP
8-Pin DIP
36
Power SIP
32
16-Pin SOIC
62
6-Pin Flatpack (8-Pin Body)
66
8-Pin SOIC
43
4-Pin Surface Mount
4-Pin Surface Mount
42
4-Pin DIP
4-Pin DIP
44
4-Pin V-DIP
4-Pin V-DIP
OptoMOS® is a registered trademark of IXYS Integrated Circuits
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 7
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
Solid State Relays
Part
Number
Relay
Type
Blocking
Voltage
(VP)
Load
Current
(mA)
On
Resistance
(W)
Input
Control
Current
(mA)
Switching
Speeds
ton / toff
(ms)
Isolation
Voltage
(VRMS)
Off-State
Leakage
(mA)
Package
Type
(Page 6)
Features and Comments
CPC1006N BI 60 75 10 0.5 10 / 10 1500 1 10 Low IF , EN 50130-4
CPC1008N BI 100 150 8 2 2 / 1 1500 1 10
CPC1009N BI 100 150 8 2 2 / 0.5 1500 0.02 10 Very low off-state ILEAK ≤ 20nA
CPC1010N BI 250 170 11.5 2 3 / 3 1500 1 10
CPC1014N BI 60 400 2 2 2 / 1 1500 1 10 EN 50130-4
CPC1016N BI 100 100 16 2 2 / 1 1500 1 10
CPC1017N BI 60 100 16 1 10 / 10 1500 1 10 Low IF , EN 50130-4
CPC1018N BI 60 600 0.8 1 3 / 2 1500 1 10 Low IF , EN 50130-4
CPC1019N BI 60 750 0.6 2 3 / 3 1500 1 10
CPC1020N BI 30 1200 0.25 2 3 / 3 1500 1 10 High load current, very low on-resistance
CPC1025N BI 400 120 30 2 2 / 1 1500 1 10
CPC1030N BI 350 120 30 2 2 / 1 1500 1 10
CPC1035N BI 350 100 35 2 2 / 1 1500 1 10
CPC1225N BI 400 120 30 2 2 / 1 1500 1 10 IEC/EN/UL 62368-1 Supplementary Insulation (0.4mm distance through insulation)
CPC1230N BI 350 120 30 2 2 / 1 1500 1 10 IEC/EN/UL 62368-1 Supplementary Insulation (0.4mm distance through insulation)
CPC1330 BI 350 120 30 2 2 / 1 5000 1 42, 43 Enhanced isolation voltage
CPC1335 BI 350 100 35 1 10 / 10 3750 1 21 Low IF , EN 50130-4 (installation class 3), transient voltage suppression (TVS)
CPC1390 BI 400 140 22 2 1 / 1 5000 1 42, 43, 44 Enhanced isolation voltage
CPC1393 BI 600 90 50 2 5 / 5 5000 1 42, 43, 44 Enhanced isolation voltage
CPC1394 BI 600 120 35 2 5 / 3 5000 1 42, 43, 44 Enhanced isolation voltage
CPC1510 BI+ 250 200 15 2 2 / 2 3750 1 12, 14 Current limiting with thermal management - see page 12
CPC1511 BI 230 450 4 2.5 4 / 2 3750 1 36 Current limiting with thermal management - see page 12
CPC1540 BI+ 350 120 25 2 2 / 2 3750 1 12, 14 Current limiting, thermal management, voltage triggered shutdown - see page 12
CPC1560 BI+ 60 300 5.6 1.1 0.1 / 0.4 3750 1 20, 22 Current limiting with thermal management - see page 12
CPC1561B BI 60 1000 0.245 2.5 2.5 / 0.5 3750 1 32 Current limiting with thermal management - see page 12
CPC1563 BI+ 600 120 35 2 2 / 2 3750 1 12, 14 Current limiting, thermal management, voltage triggered shutdown - see page 12
CPC1593 BI+ 600 120 35 2 2 / 2 3750 1 12, 14 Current limiting, thermal management, voltage triggered shutdown - see page 12
CPC1706Y UNI 60 4000 0.09 5 5 / 2 2500 1 36
CPC1726Y UNI 250 1000 0.75 10 5 / 2 2500 1 36
CPC1906Y BI 60 2000 0.3 10 10 / 5 2500 1 36
CPC1907B BI 60 6000 0.06 5 5 / 1 5000 1 66
CPC1916Y BI 100 2500 0.34 10 5 / 3 2500 1 36
CPC1926Y BI 250 700 1.4 10 10 / 10 2500 1 36
CPC1973Y BI 400 350 5 10 5 / 3 2500 1 36
CPC1981Y BI 1000 180 18 10 10 / 5 2500 1 36
CPC1983B BI 600 500 6 5 5 / 2 5000 1 66
CPC1983Y BI 600 500 6 5 5 / 2 2500 1 36
1-Form-A Relays: Single-Pole
• 1-FORM-A RELAYS (NORMALLY OPEN)
BI BI+
UNI
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
8
Solid State Relays
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
Part
Number
Relay
Type
Blocking
Voltage
(VP)
Load
Current
(mA)
On
Resistance
(W)
Input
Control
Current
(mA)
Switching
Speeds
ton / toff
(ms)
Isolation
Voltage
(VRMS)
Off-State
Leakage
(mA)
Package
Type
(Page 6)
Features and Comments
CPC1983YE BI 600 500 6 5 5 / 2 4000 1 36
CPC1984Y BI 600 1000 0.66 5 10 / 2 4000 1 36
LCA100 BI+ 350 120 25 5 5 / 5 3750 1 12, 14
LCA100L BI+ 350 120 25 5 5 / 5 3750 1 12, 14 Current limiting
LCA110 BI+ 350 120 35 2 3 / 3 3750 1 12, 14
LCA110L BI+ 350 120 35 2 3 / 3 3750 1 12, 14 Current limiting
LCA120 BI+ 250 170 20 5 3 / 3 3750 1 12, 14
LCA120L BI+ 250 150 20 5 3 / 3 3750 1 12, 14 Current limiting
LCA125 BI+ 300 170 16 5 5 / 5 3750 1 12, 14
LCA125L BI+ 300 170 20 5 5 / 5 3750 1 12, 14 Current limiting
LCA127 BI+ 250 200 10 5 5 / 5 3750 1 12, 14
LCA127L BI+ 250 170 15 5 5 / 5 3750 1 12, 14 Current limiting
LCA129 BI+ 250 170 20 2 8 / 8 3750 1 12, 14
LCA182 BI+ 350 120 35 0.25 3 / 3 3750 1 12, 14 Very low IF
LCA701 BI+ 100 1500 0.3 2 4 / 1 3750 1 12, 14 High load current
LCA710 BI+ 60 1000 0.5 10 2.5 / 0.25 3750 1 12, 14 High load current
LCA712 BI+ 60 1000 0.5 10 2.5 / 0.35 3750 0.01 12, 14 High load current, low ILEAK
LCA715 BI+ 60 2200 0.15 5 2.5 / 0.25 3750 1 12, 14 High load current
LCA717 BI+ 30 2000 0.15 2 3 / 3 3750 1 12, 14 High load current
OMA160 BI+ 250 50 100 10 0.125 / 0.125 3750 0.025 12, 14 Low ILEAK , fast switching speeds
PLA110 BI+ 400 150 22 5 1 / 0.5 3750 1 12, 14
PLA110L BI+ 400 150 25 5 1 / 0.5 3750 1 12, 14 Current limiting
PLA132 BI+ 60 600 1 2 5 / 2 3750 1 12, 14
PLA134 BI+ 100 350 3 5 5 / 5 3750 1 12, 14
PLA140 BI+ 400 250 8 5 3 / 1 3750 1 12, 14
PLA140L BI+ 400 200 13 5 5 / 3 3750 1 12, 14 Current limiting
PLA143 BI+ 600 100 50 2 5 / 5 4000 1 12, 14 Enhanced isolation voltage
PLA150 BI+ 250 250 7 5 2.5 / 0.5 3750 1 12, 14
PLA160 BI+ 300 50 100 10 0.05 / 0.05 3750 0.025 12, 14 Low ILEAK , fast switching speed
PLA170 BI+ 800 100 50 5 5 / 5 3750 1 12, 14
PLA171 BI 800 100 50 2 5 / 5 5000 1 62 Enhanced isolation voltage, high blocking voltage (output pins 7mm separation)
PLA172P BI 800 100 50 2 5 / 5 5000 1 62 −40ºC to +105ºC Operational Temperature Range
PLA190 BI+ 400 150 22 5 1 / 0.5 5000 1 12, 14 Enhanced isolation voltage
PLA191 BI+ 400 250 8 5 3 / 1 5000 1 12, 14 Enhanced isolation voltage
PLA192 BI+ 600 150 22 5 5 / 5 5000 1 12, 14 Enhanced isolation voltage
PLA193 BI+ 600 100 50 5 5 / 5 5000 1 12, 14 Enhanced isolation voltage
PLA194 BI+ 600 130 35 2 3 / 2 5000 1 12, 14 Enhanced isolation voltage
XCA170 BI+ 350 100 50 5 5 / 5 3750 1 12, 14
1-Form-A Relays: Single-Pole (continued)
BI BI+
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 9
Solid State Relays
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
1-Form-A Relays: Dual Single-Pole
Part
Number
Relay
Type
Blocking
Voltage
(VP)
Load
Current
(mA)
On
Resistance
(W)
Input
Control
Current
(mA)
Switching
Speeds
ton / toff
(ms)
Isolation
Voltage
(VRMS)
Off-State
Leakage
(mA)
Package
Type
(Page 6)
Features and Comments
CPC2014N BI 60 400 2 2 2 / 1 1500 1 17 EN 50130-4
CPC2017N BI 60 120 16 1 3 / 3 1500 1 17 Low IF , EN 50130-4
CPC2025N BI 400 120 30 2 2 / 1 1500 1 17
CPC2030N BI 350 120 30 2 2 / 1 1500 1 17
CPC2907B BI 60 2000 0.15 5 2.5 / 0.25 4000 1 66 DUAL: two independent relays in one package
LAA100 BI 350 120 25 5 5 / 5 3750 1 20, 21, 22
LAA100L BI 350 120 25 5 5 / 5 3750 1 20, 21, 22 Current limiting
LAA108 BI 100 300 8 2 3 / 3 3750 1 20, 21, 22
LAA110 BI 350 120 35 5 3 / 3 3750 1 20, 21, 22
LAA110L BI 350 120 35 5 3 / 3 3750 1 20, 21, 22 Current limiting
LAA120 BI 250 170 20 5 5 / 5 3750 1 20, 21, 22
LAA120L BI 250 150 25 5 5 / 5 3750 1 20, 21, 22 Current limiting
LAA125 BI 350 170 16 5 5 / 5 3750 1 20, 21, 22
LAA125L BI 350 150 18 5 5 / 5 3750 1 20, 21, 22 Current limiting
LAA127 BI 250 200 10 5 5 / 5 3750 1 20, 21, 22
LAA127L BI 250 170 10 5 5 / 5 3750 1 20, 21, 22 Current limiting
LAA710 BI 60 1000 0.5 10 2.5 / 0.25 3750 1 20, 22
OAA160 BI 250 50 100 6 0.125 / 0.125 3750 0.025 20, 21, 22 Very low ILEAK , fast switching speeds
PAA110 BI 400 150 22 5 1 / 0.25 3750 1 20, 21, 22
PAA110L BI 400 150 25 5 1 / 0.5 3750 1 20, 21, 22 Current limiting
PAA127 BI 280 200 10 3 0.5 / 0.5 3750 0.025 20, 21, 22 Very low ILEAK , fast switching speeds
PAA132 BI 60 600 1 2 5 / 2 3750 1 20, 22
PAA140 BI 400 250 8 5 3 / 1 3750 1 20, 21, 22
PAA140L BI 400 200 13 5 5 / 3 3750 1 20, 22 Current limiting
PAA150 BI 250 250 7 5 2.5 / 0.5 3750 1 20, 21, 22
PAA190 BI 400 150 22 5 1 / 0.5 5000 1 20, 22 Enhanced isolation voltage
PAA191 BI 400 250 8 5 3 / 1 5000 1 20, 22 Enhanced isolation voltage
PAA193 BI 600 100 50 5 5 / 5 5000 10 20, 22 Enhanced isolation voltage
XAA117 BI 60 150 16 1 5 / 5 3750 1 20, 21, 22 Low IF
XAA170 BI 350 100 50 5 5 / 5 3750 1 20, 21, 22
BI
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
10
Solid State Relays
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
1-Form-B Relays: Dual Single-Pole
1-Form-B Relays: Single-Pole
• 1-FORM-B RELAYS (NORMALLY CLOSED)
Part
Number
Relay
Type
Blocking
Voltage
(VP)
Load
Current
(mA)
On
Resistance
(W)
Input
Control
Current
(mA)
Switching
Speeds
ton / toff
(ms)
Isolation
Voltage
(VRMS)
Off-State
Leakage
(mA)
Package
Type
(Page 6)
Features and Comments
CPC1106N BI 60 75 10 0.5 10 / 10 1500 1 10 Low IF , EN 50130-4
CPC1114N BI 60 400 2 2 2 / 5 1500 1 10
CPC1117N BI 60 150 16 1 10 / 10 1500 1 10 Low IF , EN 50130-4
CPC1125N BI 400 100 35 2 2 / 2 1500 5 10
CPC1130N BI 350 120 30 2 2 / 2 1500 5 10
CPC1135N BI 350 120 35 2 2 / 2 1500 5 10
CPC1150N BI 350 120 50 2 1 / 2 1500 5 10
CPC1231N BI 350 120 30 2 2 / 2 1500 5 10 IEC/EN/UL 62368-1 Supplementary Insulation (0.4mm distance through insulation)
CPC1333 BI 350 130 30 2 2 / 3 5000 1 42, 43 Enhanced isolation voltage
CPC1705Y UNI 60 3250 0.09 5 2 / 12 2500 1 36
LCB110 BI+ 350 120 35 5 3 / 3 3750 1 12, 14
LCB111 BI+ 350 120 35 2 5 / 5 3750 1 12, 14
LCB120 BI+ 250 170 20 5 5 / 5 3750 1 12, 14
LCB126 BI+ 250 170 15 5 5 / 5 3750 1 12, 14
LCB127 BI+ 250 200 10 5 5 / 5 3750 1 12, 14
LCB710 BI+ 60 1000 0.6 2 3 / 3 3750 1 12, 14 High load current
LCB716 BI+ 60 500 2 2 3 / 3 3750 1 12, 14
LCB717 BI+ 30 1500 0.3 2 2 / 5 3750 1 12, 14 High load current
PLB150 BI+ 250 250 7 5 1 / 2.5 3750 1 12, 14
PLB171 BI 800 80 55 2 5 / 5 5000 1 62 Enhanced isolation voltage, high blocking voltage (output pins 7mm separation)
PLB190 BI+ 400 130 25 2 1 / 2.5 5000 1 12, 14 Enhanced isolation voltage
XCB170 BI+ 350 100 50 5 5 / 5 3750 1 12, 14
Part
Number
Relay
Type
Blocking
Voltage
(VP)
Load
Current
(mA)
On
Resistance
(W)
Input
Control
Current
(mA)
Switching
Speeds
ton / toff
(ms)
Isolation
Voltage
(VRMS)
Off-State
Leakage
(mA)
Package
Type
(Page 6)
Features and Comments
CPC2125N BI 400 100 35 2 2 / 2 1500 5 17
LBB110 BI 350 120 35 5 3 / 3 3750 1 20, 21, 22
LBB120 BI 250 170 20 5 5 / 5 3750 1 20, 22
LBB126 BI 250 170 15 5 5 / 5 3750 1 20, 21, 22
LBB127 BI 250 200 10 5 5 / 5 3750 1 20, 21, 22
PBB150 BI 250 250 7 5 2.5 / 2.5 3750 1 20, 21, 22
PBB190 BI 400 130 25 2 1 / 2.5 5000 1 20, 22
XBB170 BI 350 100 50 5 5 / 5 3750 1 20, 21, 22
BI
BI BI+
UNI
$4
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 11
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
Solid State Relays
1-Form-A & 1-Form-B Combination Relays
1-Form-A Relays: Single-Pole, Unidirectional (DC-only)
Part
Number
Relay
Type
Blocking
Voltage
(VP)
Load
Current
(mA)
On
Resistance
(W)
Input
Control
Current
(mA)
Switching
Speeds
ton / toff
(ms)
Isolation
Voltage
(VRMS)
Off-State
Leakage
mA)
Package
Type
(Page 6)
Features and Comments
CPC1002N UNI 60 700 0.55 2 5 / 2 1500 1 10 EN 50130-4
CPC1004N UNI 100 300 4 2 3 / 1 1500 1 10 Extended operating temperature range: −40ºC to +110ºC
• MISCELLANEOUS RELAYS
Part
Number
Relay
Type
Blocking
Voltage
(VP)
Load
Current
(mA)
On
Resistance
(W)
Input
Control
Current
(mA)
Switching
Speeds
ton / toff
(ms)
Isolation
Voltage
(VRMS)
Off-State
Leakage
A/B
(mA)
Package
Type
(Page 6)
Features and Comments
CPC2317N BI 60 120 16 1 3 / 3 1500 1 / 1 17 Low IF
CPC2330N BI 350 120 30 2 3 / 3 1500 1 / 5 17
LBA110 BI 350 120 35 2 3 / 3 3750 1 / 1 20, 21, 22
LBA110L BI 350 120 35 5 3 / 3 3750 1 / 1 20, 21, 22 Current limiting
LBA120 BI 250 170 20 5 5 / 5 3750 1 / 1 20, 21, 22
LBA120L BI 250 150 25 5 5 / 5 3750 1 / 1 20, 22 Current limiting
LBA127 BI 250 200 10 5 5 / 5 3750 1 / 1 20, 21, 22
LBA127L BI 250 150 15 5 5 / 5 3750 1 / 1 20, 22 Current limiting
LBA710 BI 60 1000 0.6 2 5 / 5 3750 1 / 1 20, 22 High load current
LBA716 BI 60 1000 0.4 2 5 / 5 3750 1 / 1 20, 22 High load current (Normally closed pole load current = 500mA)
PBA150 BI 250 250 7 5 2.5 / 2.5 3750 1 / 1 20, 22
UNI
BI
2-Form-A Relays: Double-Pole, Single-Throw
Part
Number
Relay
Type
Blocking
Voltage
(VP)
Load
Current
(mA)
On
Resistance
(W)
Input
Control
Current
(mA)
Switching
Speeds
ton / toff
(ms)
Isolation
Voltage
(VRMS)
Off-State
Leakage
(mA)
Package
Type
(Page 6)
Features and Comments
LCA210 BI 350 85 35 8 3 / 3 3750 1 20, 22
LCA210L BI 350 85 35 8 4 / 4 3750 1 20, 22 Current limiting
LCA220 BI 250 120 20 10 5 / 5 3750 1 20, 22
BI
1-Form-C Relays: Common Input, Single-Pole, Double-Throw
Part
Number
Relay
Type
Blocking
Voltage
(VP)
Load
Current
(mA)
On
Resistance
(W)
Input
Control
Current
(mA)
Switching
Speeds
ton / toff
(ms)
Isolation
Voltage
(VRMS)
Off-State
Leakage
(mA)
Package
Type
(Page 6)
Features and Comments
LCC110 BI 350 120 35 8 4 / 4 3750 1 20, 21, 22
LCC120 BI 250 170 20 10 5 / 5 3750 1 20, 22
BI
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
12 For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
• Provide excellent power-cross immunity
• Resumes normal operation after fault is removed
• Ideal for use in electromagnetically noisy environments
• ACTIVE CURRENT LIMITING SSRS WITH VOLTAGE TRIGGERED SHUTDOWN & THERMAL MANAGEMENT
FAULT PROTECTED SOLID STATE RELAYS
* Load current is reduced to approximately 100mA or less whenever the voltage across the switches exceeds the threshold VTH while the relay is in current limit.
Part Number Blocking
Voltage
Input Control
Current
On-Resistance
(Maximum)
Load Current
(Maximum)
Current Limit
(Maximum)
* VTS
Threshold
Switching
Speed
Isolation
Voltage
Package
Type
Features & Comments
DC-Only AC DC-Only AC DC-Only AC (VTH) (ton / toff)
(VP) (mA) (W) (W) (mA) (mA) (mAP) (mAP) (V) (ms) (VRMS)
CPC1510 250 2 3.75 15 350 200 920 450 - 2 / 2 3750 12, 14 Industrial applications
CPC1511 230 2.5 - 4 - 450 - 1400 - 4 / 2 3750 36 Industrial applications
CPC1540 350 2 6.75 25 250 120 570 285 100 2 / 2 3750 12, 14 PSTN hook switch applications
CPC1560 60 1.1 1.4 5.6 600 300 1500 900 - 0.1 / 0.4 3750 20, 22 Fast switching speeds
CPC1561B 60 2.5 - 0.245 - 1000 - 3000 - 2.5 / 0.5 3750 32 1A Load current rating to 60°C
CPC1563 600 2 11.75 35 250 120 570 285 100 2 / 2 3750 12, 14 High blocking voltage
CPC1593 600 2 11.75 35 250 120 570 285 21 2 / 2 3750 12, 14 Power supply start-up
All of the Fault Protected Solid State Relays (SSR) listed below feature Active Current Limiting and Thermal Management while the CPC1540, CPC1563, and CPC1593
additionally feature Voltage Triggered Shutdown, or VTS.
Fault Protected SSRs can directly replace footprint-compatible standard SSRs in existing designs to improve end-product survivability.
These Fault Protected relays resume normal operation upon removal of the fault condition or upon cycling the input control current. Should the fault condition repeat or
persist, the fault protection will immediately resume.
Active Current Limiting: All Fault Protected SSRs limit load current to protect both the load and the SSR.
Voltage Triggered Shutdown: CPC1540, CPC1563, and CPC1593 incorporate a third protection feature called Voltage Triggered Shutdown (VTS). During a current
limiting event this advanced thermal management protection feature reduces the relay current to <100µA whenever the voltage drop across the relay exceeds a
non-adjustable predetermined threshold thereby preventing excessive heating of the SSR.
Thermal Management: All Fault Protected relays include the traditional thermal management feature that deactivates the SSR outputs anytime the die temperature
exceeds a safe limit regardless of the Active Current Limiting state and when equipped, the Voltage Triggered Shutdown state. This feature provides excellent power cross
immunity.
Fault Protected Solid State Relays
sq im mum {Q If
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 13
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
12
6-Pin Surface Mount
14
6-Pin DIP
6-Pin DIP
22
8-Pin Surface Mount
36
Power SIP
32
16-Pin SOIC
20
8-Pin DIP
8-Pin DIP
Current
Limit
Gate Drive
Control
Thermal
Management
Performance into resistive load.
I
LMT
Current Through Relay
Time
I
LMT
Load Voltage
With ILIMIT
Without VTS
Thermal
Management
Gate Drive
Control
Voltage
Triggered
Shutdown
S1
S2
OUT1
OUT2
OUT1
OUT2
S1
S2
Voltage Threshold Shutdown Delay
Voltage Threshold Shutdown Reactivation Delay
Current Through Relay
Load Voltage
V
TH
I
LMT
Time
V
TH
I
LMT
Performance into resistive load.
Voltage Threshold
With ILIMIT
With VTS
Fault Protected Solid State Relays
SOLATED WER RELAYS - Blocking 0 st n 30° 1 2 4 1 2 3 4 + + , - + 1- Form- A 1- Form-A Bidirectional Unidirectional Heat dissipating, isolating substrate is heat-sink compatible for higher current applications M5) (I) > L“ a) D: L a) 3 o D. '0 a) .. L“ o 2 2‘ Ta 0 '5 o. O
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
14 For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
Applications:
• Medical equipment
• Railroad/traffic controls
• Industrial control
• Test and measurement equipment
29 - i4-PAC
29 - i4-PAC
• Blocking voltage up to 1000VP
• On-resistance as low as 0.05 Ohms
• On/off times from 5ms to 25ms
• MOSFET-based AC/DC and DC-only power relays
• Load current up to 22.8ADC (with 5ºC/W heat sink)
• 2500VRMS isolation from input to output
and to the ceramic substrate
Features:
• Isolated, low thermal impedance pad for heat sink applications
• Low input control current
• Low thermal impedances, junction to case (qJC):
0.30°C/W - ISOPLUS-264
0.35°C/W - i4-PAC
1.50°C/W - Power SIP
1.50°C/W - Power SOIC
37 - ISOPLUS-264
MOSFET-based AC/DC and DC-only power relays
MOSFET-based AC/DC and DC-only power relays
MOSFET-based AC/DC and DC-only power relays
MOSFET-based AC/DC and DC-only power relays
MOSFET-based AC/DC and DC-only power relays
MOSFET-based AC/DC and DC-only power relays
MOSFET-based AC/DC and DC-only power relays
(with 5ºC/W heat sink)
(with 5ºC/W heat sink)
(with 5ºC/W heat sink)
(with 5ºC/W heat sink)
(with 5ºC/W heat sink)
(with 5ºC/W heat sink)
(with 5ºC/W heat sink)
JC
):
OPTICALLY ISOLATED POWER RELAYS
Heat dissipating, isolating substrate is heat-sink
compatible for higher current applications
+ -
1-Form-A
Bidirectional
1-Form-A
Unidirectional
Optically Isolated Power Relays
IXYS Aliflellun Tecmm‘ogy % D :E Y +§ >7 +a .m _ +4} ——L . F A; _N
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 15
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
• 1-FORM-A POWER RELAYS: SINGLE-POLE - UNIDIRECTIONAL
• 1-FORM-A POWER RELAYS: SINGLE-POLE - BIDIRECTIONAL
Part Number Relay
Type
Blocking
Voltage
(VP)
Load Current
(A)
On
Resistance
(W)
Input
Control
Current
(mA)
Switching
Speeds
ton / toff
(ms)
Isolation
Voltage
(VRMS)
Off-State
Leakage
(mA)
Package
Type
(Page 14)
Features & Comments
Without
Heat Sink
5ºC/W
Heat Sink
TC=25ºC
CPC1708J UNI 60 4 11.85 24 0.08 10 20 / 5 2500 1 29
CPC1709J UNI 60 9 22.8 32 0.05 10 20 / 5 2500 1 37
CPC1718J UNI 100 6.75 17.5 32 0.075 10 20 / 5 2500 1 37
CPC1727J UNI 250 3.4 8.6 20 0.09 10 20 / 5 2500 1 37
CPC1777J UNI 600 1.5 4.6 15 0.5 10 20 / 5 2500 1 29
CPC1779J UNI 600 1.65 4.12 15 0.4 10 20 / 5 2500 1 37
CPC1786J UNI 1000 0.65 1.75 6.9 2 10 20 / 5 2500 1 29
CPC1788J UNI 1000 1 2.45 10.3 1.25 10 20 / 5 2500 1 37
Part Number Relay
Type
Blocking
Voltage
(VP)
Load Current
(ARMS)
On
Resistance
(W)
Input
Control
Current
(mA)
Switching
Speeds
ton / toff
(ms)
Isolation
Voltage
(VRMS)
Off-State
Leakage
(mA)
Package
Type
(Page 14)
Features & Comments
Without
Heat Sink
5ºC/W
Heat Sink
TC=25ºC
CPC1908J BI 60 3.5 8.5 15 0.3 10 20 / 5 2500 1 29
CPC1909J BI 60 6.5 15 15 0.1 10 25 / 10 2500 1 37
CPC1918J BI 100 5.25 13 15 0.1 10 25 / 10 2500 1 37
CPC1927J BI 250 2.7 6.7 15 0.2 10 25 / 10 2500 1 37
CPC1967J BI 400 1.35 3.35 13.15 0.85 10 20 / 5 2500 1 29
CPC1968J BI 500 2 5 15 0.35 10 20 / 5 2500 1 37
CPC1977J BI 600 1.25 3.1 12.25 1 10 20 / 5 2500 1 29
CPC1978J BI 800 0.75 1.85 7.25 2.3 10 20 / 5 2500 1 29
CPC1979J BI 600 1.4 3.5 14.5 0.75 10 25 / 5 2500 1 37
CPC1986J BI 1000 0.65 1.6 6.5 3 10 20 / 5 2500 1 29
CPC1988J BI 1000 0.9 2.25 9.4 2.5 10 20 / 5 2500 1 37
+ -
Optically Isolated Power Relays
- Blocking voltage trom 400VP to r A w. mp Ger Paw.- m? In IN 6er Power mp 5mm. Mm IQ im
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
16 For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
Features:
• 5mA input sensitivity
• Zero-cross turn on ≤ ½ Cycle
• Low EMI and RFI generation
• DC control, AC switching
• Optically isolated
• TTL and CMOS compatible
• High noise immunity
• Machine insertable, wave solderable
ZC
Zero-Cross Turn-On
• Contactors
• Solenoids
• Motor controls
• Heater controls
Applications:
• Programmable controls
•Process control
• Power control panels
• Remote switching
• Gas pump electronics
• OPTICALLY ISOLATED AC POWER SWITCHES: LOAD CURRENT ≤1A
2
14
16
22
12
15
20
23
4-Pin DIP (16-Pin Body)
6-Pin DIP
6-Pin Power DIP Surface Mount
8-Pin Surface Mount
6-Pin Surface Mount
6-Pin Power DIP
8-Pin DIP
4-Pin SIP (8-Pin Body)
6-Pin DIP
6-Pin Power DIP
8-Pin DIP
• Blocking voltage from 400VP to 800VP
• SCR-based AC power switches
• Maximum load current up to 1ARMS
Part Number Blocking
Voltage
(VP)
Load
Current
(ARMS)
Input
Control
Current
(mA)
Operating
Frequency
Min / Max
(Hz)
Isolation
Voltage
(VRMS)
Package
Type
CPC1943 400 0.5 5 20 - 500 3750 15, 16
CPC1945G 400 1 5 20 - 400 3750 2
CPC1945Y 400 1 5 20 - 400 3750 23
CPC1961 Dual 600 0.25 15 20 - 500 3750 20, 22
CPC1963 600 0.5 5 20 - 500 3750 15, 16
CPC1965G 600 1 5 20 - 400 3750 2
CPC1965Y 600 1 5 20 - 400 3750 23
CPC1972 800 0.25 5 20 - 500 3750 12, 14
PD1201 400 1 5 20 - 500 3750 2
PD2401 500 1 5 20 - 500 3750 2
PD2601 600 1 5 20 - 500 3750 2
PM1204 400 0.5 5 20 - 500 3750 15, 16
PM1205 500 0.5 5 20 - 500 3750 15, 16
PM1206 600 0.5 5 20 - 500 3750 15, 16
PS1201 400 1 5 20 - 500 3750 23
PS2401 500 1 5 20 - 500 3750 23
PS2601 600 1 5 20 - 500 3750 23
1 Maximum continuous load current of a single pole or the sum of the load currents with both poles operating simultaneously.
OPTICALLY ISOLATED AC POWER SWITCHES
Optically Isolated AC Power Switches
IXYS Almeunu Tecmm‘ogy % 29 - i4-PAC I’lfl Rapid turn-on (non-zero- 64 - SuperSlP Efl1¢
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 17
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
• OPTICALLY ISOLATED AC POWER SWITCHES: LOAD CURRENT >1A
64 - SuperSIP 66 - Power SOIC
36 - Power SIP
29 - i4-PAC
29 - i4-PAC
64 - SuperSIP
Rapid turn-on (non-zero-cross)
Rapid turn-on devices turn on when the control input goes true regardless of
the load voltage phase, and turn off when the load current crosses zero.
• Blocking voltages of 600VP and 800VP
• SCR-based AC power switches
• Zero-cross and Rapid turn-on (non-zero-cross) versions
*
Part
Number
Blocking
Voltage
(VP)
Load Current Input
Control
Current
(mA)
Input
Control
Voltage
(V)
Operating
Frequency
Min / Max
(Hz)
Turn-On:
Zero-Cross
or
Rapid
Switching
Speed
ton / toff
(max)
Isolation
Voltage
(VRMS)
Package
Type
Features
Without
Heat Sink
(ARMS)
5ºC/W
Heat Sink
(ARMS)
TC=25ºC
(ARMS)
CPC1964B 800 1.5 - - 5 - 20 - 500 Zero-cross ½ Cycle 5000 66 Enhanced isolation voltage, 12.5mm creepage
CPC1964BX6 600 1.5 - - 5 - 20 - 500 Rapid 500ms / ½ Cycle 5000 66 Rapid turn-on, enhanced isolation voltage
CPC1966Y 600 3 - - 5 - 20 - 500 Zero-cross ½ Cycle 3750 36
CPC1966B 800 3 - - 5 - 20 - 500 Zero-cross ½ Cycle 5000 66 Enhanced isolation voltage, 12.5mm creepage
CPC1966BX8 800 3 - - 5 - 20 - 500 Rapid **45ms / ½ Cycle 5000 66 Rapid turn-on, 12.5mm creepage
CPC1966YX6 600 3 - - 5 - 20 - 500 Rapid 500ms / ½ Cycle 3750 36 Rapid turn-on
CPC1966YX8 800 3 - - 5 - 20 - 500 Rapid **45ms / ½ Cycle 3750 36 Rapid turn-on
CPC1976 600 2 - - 5 - 20 - 500 Zero-cross ½ Cycle 3750 36
CPC1976YX6 600 2 - - 5 - 20 - 500 Rapid 500ms / ½ Cycle 3750 36 Rapid turn-on
CPC1998J 800 5 20 50 5 - 20 - 500 Zero-cross ½ Cycle 2500 29 High load current
CPC40055ST 800 5 20 40 5 - 20 - 500 Zero-cross ½ Cycle 2500 64 High load current, 8.788mm creepage
** Typical turn-on values.
*
*
*
*
*
Heat dissipating, isolating substrate is heat-sink
compatible for higher current applications
Optically Isolated AC Power Switches
W W W :7}, ,g, 3}, i7 i7
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
18 For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
• LOW-SIDE GATE DRIVERS
Features:
• 1.5A to 30A peak source/sink drive current
• Wide operating voltage range
• −40°C to +125°C extended operating temperature range
• Logic input withstands negative swing of up to −5V
• Dual drivers have matched rise and fall times
• Low propagation delay time
• Low output impedance
Applications:
• Efficient power MOSFET and IGBT switching
• Switch mode power supplies
• Motor controls
• DC to DC converters
• Class-D switching amplifiers
• Pulse transformer driver
AEC-Q100 qualified:
IXD_604SI & SIA
IXD_609SI
IXD_614SI
IX4340NE
AEC-Q100 Qualified Low-Side Gate Drivers
EN
IN OUT IN OUT IN OUT
INA
INB
AOUTA
OUTB
B
INA
INB
OUTA
OUTB
B
A
INA
INB
OUTA
OUTB
A
B
ENB
INB
OUTA
OUTB
A
B
ENA
INA
FI ND
Part
Number
Output
Type
IPEAK
TC=25ºC
(AP)
Output
Resistance
(W)
Available
Logic
Configurations
Enable
Function
Package
Type
IXD_604SI DUAL 4 2.5 D, I, N, F •82
IXD_604SIA DUAL 4 2.5 D, I, N, F •81
IX4340NE DUAL 5 1.5 D •82
IXD_609SI SINGLE 9 1 D, I, N •82
IXD_614SI SINGLE 14 0.8 D, I, N •82
20
8-Pin DIP
8-Pin DIP
82 8-Pin SOIC-EP
81 8-Pin SOIC
56
8-Pin DFN
57
5-Pin TO-220
58
5-Pin TO-263
8-Pin MSOP-EP
92
IGBT & MOSFET GATE DRIVERS
Part
Number
Output
Type
IPEAK
TC=25ºC
(AP)
Output
Resistance
(W)
Available
Logic
Configurations
Enable
Function
Under-voltage
Lockout
(V)
Package Type
IX4426 DUAL 1.5 8 I -- 56, 81
IX4427 DUAL 1.5 8 N -- 56, 81
IX4428 DUAL 1.5 8 F -- 56, 81
IX4310T SINGLE 2 3 N -VCC < 4.2 99
IXD_602 DUAL 2 4 F, I, N -- 20, 56, 81, 82
IXD_604 DUAL 4 2.5 F, I, N, D •- 20, 56, 81, 82
IX4340 DUAL 5 1.5 D •VCC < 3.8 81, 82, 92
IXD_609 SINGLE 9 1 I, N, D •- 20, 56, 57, 58, 81, 82
IXD_614 SINGLE 14 0.8 I, N, D •- 20, 57, 58, 82
IXD_630 SINGLE 30 0.4 I, N, D •VCC < 12.5 57, 58
IXD_630M SINGLE 30 0.4 I, N, D •VCC < 9 57, 58
IGBT & MOSFET Gate Drivers
99
5-Pin SOT23
IXYS Almeunu Tecmm‘ogy % if i 1% E :44 f 35; ” IQ
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 19
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
Features:
• No external IC power supply required
• Low drive power requirements (TTL/CMOS compatible)
• Load voltages up to 200V
• Fast switching speeds: 40ms on, 400ms off
Applications:
• Instrumentation
• Multiplexers
• I/O subsystems
• Meters (Watt-Hour, water, gas)
• Medical equipment (patient/equipment isolation)
• Security
• Industrial controls
CPC1590 Application Diagram
Part Number Input Control Current
(mA)
Gate Voltage @ IF=5mA
(VG)
Blocking Voltage
(VP)
Regulated Capacitor Voltage
(VCAP-MAX)
Switching Speeds
ton / toff (ms)
Isolation Voltage
(VRMS)
CPC1580 2.5 7.5 - 12 65 VDS - 0.2V 40 / 400 3750
CPC1590 2.5 7.5 - 12 200 16 40 / 400 3750
• OPTICALLY ISOLATED LOAD-BIASED GATE DRIVERS
8-Pin Flatpack
• High speed, optically isolated gate driver ICs
• Output driver powered from load voltage; no external power supply required
• On-chip circuitry charges an external capacitor whose charge enables fast turn-on
2
3
1
4
NC
NC
8
5
6
7
CAP
+VLOAD
G
-VLOAD
CST
A
B
RLED
+V
LOAD
Part Number Input Control Current
(mA)
Nominal Open-Circuit
Voltage VOC (V)
Nominal Short-Circuit
Current ISC (mA)
Switching Speeds
ton / toff (ms)
Isolation Voltage
(VRMS)
Package Type
FDA215 5 5.5 2.5 5 / 5 3750 8-pin DIP, 8-pin surface mount
FDA217 5 11.75 4.5 2 / 0.5 3750 8-pin DIP, 8-pin surface mount
• OPTICALLY ISOLATED PHOTOVOLTAIC GATE DRIVERS
Input Output
Input Output
PV
PV
Features:
• Isolated 5.5V and 12V photovoltaic output
• Floating outputs for parallel or series configuration
Applications:
• MOSFET driver
• Isolated floating power source
8-Pin Surface Mount
8-Pin DIP
8-Pin DIP
• Dual optically isolated photovoltaic devices
• Well suited for use in discrete solid state relay designs
IGBT & MOSFET Gate Drivers
fig
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
20 For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
• CPC1596: 570V OPTICALLY ISOLATED LOAD-BIASED GATE DRIVER
Features:
• Requires No Load-side Power Supply
• Drives External Power MOSFET
• Only 2.5mA Input LED Current to Drive External MOSFET
• 3750VRMS Input-to-Output Isolation
Applications:
Optically Isolated AC or DC Relays for:
• Industrial Controls
• Instrumentation
• Medical Equipment Isolation
• Electronic Switching
• I/O Subsystems
• Appliances
CPC1596
+ VLOAD
NC
NC
1
4
2
3
7
8
5
6
Q1
CST
LOAD
+ VLOAD
Q2
LED+
LED-
C
A
G
B
CPC1596 AC Application Circuit
The CPC1596 is an optically isolated, load-biased Gate Driver that requires no additional power supply to bias the external MOSFET gates; in the off-state it regulates the
voltage drawn from the load (up to 570V) down to 12.2V for internal use. It is specifically designed for low duty cycle switching applications such as an optically isolated
DC relay using a single MOSFET or an AC relay with two MOSFETs.
The CPC1596 accomplishes very fast MOSFET turn-on by supplying charge stored in an external capacitor to the MOSFET gate when input control current is applied to
the device’s LED. After the MOSFET is turned on, photocurrent from the internal optocoupler keeps the MOSFET active for as long as sufficient input control current is
applied assuring very low-frequency operation. When the MOSFET is turned off, the storage capacitor charges from the load voltage via the regulated internal voltage in
preparation for the next turn-on.
Provided in a small, 8-pin package and requiring no separate power supply, the CPC1596 provides a flexible design solution that minimizes PCB real estate.
CPC1596
+ VLOAD
NC
NC
1
4
2
3
7
8
5
6
Q1
CST
LOAD
- VLOAD
LED+
LED-
C
A
G
B
CPC1596 DC Application Circuit #1
CPC1596
+ VLOAD
NC
NC
1
4
2
3
7
8
5
6
Q1
CST LOAD
- VLOAD
LED+
LED-
C
A
G
B
+ V
CPC1596 DC Application Circuit #2
IGBT & MOSFET Gate Drivers
— fl ‘ Almeumkmmav
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 21
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
SiC MOSFET & IGBT Gate Drivers
SIC MOSFET & IGBT GATE DRIVERS
Applications:
• Driving SiC MOSFETs and IGBTs
• On-board charger and DC charging station
• AC/DC and DC/DC converters
• Industrial power inverters
• Motor controllers
• AEC-Q100 Automotive-Grade qualified: IX4351NEAU
• Separate 9A peak source and sink outputs
• Generates negative gate drive voltage
• Operating voltage range: −10V to +25V
• Configurable charge pump for setting preferred negative gate drive bias
• Desaturation detection with soft shutdown sink driver
• Under Voltage Lockout (UVLO)
• Thermal shutdown
• Open drain FAULT output
• TTL and CMOS compatible input
• IX4351NE 9A LOW-SIDE GATE DRIVER
• IX4351NEAU AEC-Q100 AUTOMOTIVE QUALIFIED VERSION
The IX4351NE is designed specifically to drive SiC
MOSFETs and high power IGBTs. Separate 9A source
and sink outputs allow for tailored turn-on and turn-off
timing while minimizing switching losses. An internal
negative charge regulator provides a selectable negative
gate drive bias for improved dV/dt immunity and faster
turn-off.
Desaturation detection circuitry senses an over
current condition of the SiC MOSFET or IGBT and
initiates a soft turn off, thus preventing a potentially
damaging dV/dt event. The non-inverting logic input,
IN, is TTL and CMOS compatible; internal level shifters
provide the necessary bias to accommodate negative
gate drive bias voltages. Additional protection features
include UVLO detection and thermal shutdown. An
open drain FAULT output signals a fault condition to
the microcontroller.
The IX4351NE is rated for an operational temperature
range of −40°C to +125°C, and is available in a thermally
enhanced 16-pin narrow SOIC package.
IN
FAULT
VREG
SET
GND
COM
CAP
INSOFT
OUTSOFT
VSS
OUTSNK
OUTSRC
VDD
DESAT RDESAT
CBLANK
CDD
+22V
RH
RL
RSOFT
CREG
CF LY
CSS
DRAIN
SOURCE
GATE
Controller
R1
R2
VSS
Charge
Pump
Control
Gate and
Control
Logic
4.6V
Regulator
VDD
VDD
2.6V
6.8V
VDD
D1
RF LY
4
3
2
1
16
15
10
14
13
12
11
7
9
8
6
5
IX4351NE
V+
RIN
VSS
LOAD
IX4351NEAU
Automotive-Grade
AEC-Q100 Qualified
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
22 For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
HIGH VOLTAGE ISOLATED ANALOG SWITCHES
• CPC7524: 600V Quad High Voltage Isolated Analog Switch Array
• Provides flexible single-ended or differential access to high voltage networks
• Configured as two sets of matched, paired switches for improved differential performance
Features:
• Switch voltage up to 600VP
• 110dB switch-to-switch isolation at 5kHz
• Flexible switch configurations
• Smart logic for power-up/hot-plug state control
• 3.3V operation with very low power consumption
• Switch current limiting and thermal shutdown
protect against fault conditions
• TTL logic-level inputs
• Input latch
• Matched RON
• Clean, bounce-free switching
• Monolithic IC reliability
• 28-pin SOIC package
Applications:
• Instrumentation
• Industrial controls and monitoring
• Automatic test equipment (ATE)
• Battery monitoring and charging circuits
• Worldwide AC mains monitor
VDD = 3.3V
CHANNEL 1-2
S1
S2
S2*
S1*
S1B
S2B
S2A
S1A
TSD1-2
LATCH1-2
IN1
IN2
Channel 1-2
Switch
Control
Logic
L
A
T
C
H
1-2
CHANNEL 3-4
S3
S4
S4*
S3*
S3B
S4B
S4A
S3A
TSD3-4
LATCH3-4
IN3
IN4
Channel 3-4
Switch
Control
Logic
L
A
T
C
H
3-4
* ±600V
CPC7524
28-Pin SOIC
High Voltage Isolated Analog Switches
fl ‘ AlmellnuTechno‘ogv
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 23
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
20-Pin SOIC
VDD = 3.3V
Channel 1-2
S1
S2
S2*
S1*
S1B
S2B
S2A
S1A
TSD1
LATCH1
IN1
IN2
Channel 1-2
Switch
Control
Logic
L
A
T
C
H
1
Channel 3-4
S3
S4
S4*
S3*
S3B
S4B
S4A
S3A
TSD2
LATCH2
IN3
IN4
Channel 3-4
Switch
Control
Logic
L
A
T
C
H
2
* ±320V
Features:
• Low, matched RON
• Switch voltage up to ±320VP
• 320V logic-input-to-switch-output isolation
• 110dB switch-to-switch isolation at 5kHz
• Flexible switch configurations
• Smart logic for power-up/hot-plug state control
• 3.3V operation with very low power consumption
• Switch current limiting protects against fault conditions
• Thermal shutdown protects against fault conditions
• Latched TTL logic level inputs
• Clean, bounce-free switching
• Monolithic IC reliability
Applications:
• Instrumentation
• Industrial controls and monitoring
• Automatic test equipment (ATE)
• Battery charging circuits
• Telephony
VoIP gateways
Central office (CO) and remote terminal (RT)
Concentrators
PBX systems
Optical network terminals (ONT)
Optical network units (ONU)
Hybrid fiber coax (HFC)
• CPC7514: 320V Quad High Voltage Isolated Analog Switch Array
CPC7514
• Provides single-ended or differential access to high voltage networks
• Self-biasing - no external high-voltage supplies required
High Voltage Isolated Analog Switches
- Provides 20 pm we iHHH-H +20 _ lnse ass Into 50!! {Transfer Gain into 500 mo 50!! o 2 i a 3 E 4 E .5 s 40 ,10 a 420 420 440 440 w Frequency Frequency (
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
24 For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
Features:
• Low, matched RON
• Guaranteed break-before-make (BBM)
• Switch voltage up to ±320VP
• 60dB off-isolation at 1MHz
• Smart logic for power-up/hot-plug state control
• 5V operation with very low power consumption
• Thermal shutdown protects against fault conditions
• Latched TTL logic level inputs
Applications:
• Instrumentation
• Industrial controls and monitoring
• Multiplexed ultrasonic transducer switching
• Automatic test equipment (ATE)
• Battery monitoring and charging
• CPC7512: 320V Dual Shunt-Isolated High Voltage High Frequency Analog Switch
S1B
S1C
S1COM
S1A
TSD
LATCH1
S1Sel0
S1Sel1
Switch 1
Control
Logic
L
A
T
C
H
S2B
S2C
S2COM
S2A
LATCH2
Switch 2
Control
Logic
L
A
T
C
H
S2Sel0
S2Sel1
SW1ASW1B
SW1C
SW2ASW2B
SW2C
CPC7512
20-Pin SOIC
20-Pin SOIC
• Provides single-ended or differential access to high voltage networks
• Self-biasing: no external high-voltage supplies required
Frequency
1kHz 10kHz 100kHz 1MHz 10MHz
100MHz
Transfer Gain (dB)
-140
-120
-100
-80
-60
-40
-20
0
Crosstalk into 50Ω
Frequency (Hz)
1.0E+03 1.0E+04 1.0E+05 1.0E+06 1.0E+07
1.0E+08
Transfer Gain (dB)
-140
-120
-100
-80
-60
-40
-20
0
Open Circuit Transfer Gain into 50Ω
Frequency
1kHz 10kHz 100kHz 1MHz 10MHz 100MHz
1GHz
Loss (dB)
10
8
6
4
2
0
Insertion Loss Into 50Ω
V
M
+
VS50Ω
+20 log VS
VM
Inser
tion Loss = AB
C
Open Circuit
=
+20 log
VM
VS
V
M
+
VS50Ω
AB
C
Crosstalk
=
+20 log
VM
VS
V
M
+
50Ω
VS
Open
Open
AB
C
AB
C
High Voltage Isolated Analog Switches
1% 1%
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 25
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
Optocouplers
OPTOCOUPLERS
Part
Number
Servo Gain
K1=I1/IF
(Min - Max)
Forward Gain
K2=I2/IF
(Min - Max)
Transfer Gain
K3=K2/K1
(Min - Max)
Input Control
Current
(mA)
Isolation
Voltage
(VRMS)
Package
Type
LOC110 0.004 - 0.03 0.004 - 0.03 0.668 - 1.179 2 - 10 3750 20, 21, 22
LOC111 0.008 - 0.03 0.006 - 0.03 0.733 - 1.072 2 - 10 3750 20, 21, 22
LOC112 0.004 - 0.03 0.004 - 0.03 0.733 - 1.072 2 - 10 3750 20, 21, 22
LOC117 0.008 - 0.03 0.006 - 0.03 0.887 - 1.072 2 - 10 3750 20, 21, 22
– LED
+ LED
C1
A1
C2
A2
LOC11x
Features:
• Couples analog & digital signals
• 3750VRMS input-to-output isolation
• 200kHz bandwidth in photoconductive mode
• 40kHz bandwidth in photovoltaic mode
• High gain stability
• Low input-to-output capacitance
• Low power consumption
• 0.01% servo linearity
• THD 87dB typical
Applications:
• Power supply feedback voltage/current
• Industrial and medical sensors
• Isolation of process control transducers
• Isolated 4-20mA converters
8-Pin DIP 20
• Input LED drives two photodiodes: (1) feedback to correct for the input LED’s non-linearity (2) isolated output
Photoconductive Mode:
• 200kHz bandwidth
• 8-bit linearity
Isolation Amplifier
Photovoltaic Mode
Photovoltaic Mode:
• 14-bit linearity
• 40kHz bandwidth
VOUT
VIN
VCC
I1
IF
I2 = K3I1
LOC110, LOC111
LOC112, or LOC117
1
2
4
8
7
6
5
3
+
–
+
–
8-Pin Flatpack 21
8-Pin Surface Mount 22
• SINGLE OPTOCOUPLER
Features:
• 100mA continuous load rating
• Breakdown voltage: 30V
• Minimum current transfer ratio: 100%
• 1500VRMS Input/Output isolation
• 4-pin SOP package
Applications:
• Logic signal isolation
• Sensor circuitry
• Instrumentation
• Industrial control
Part
Number
Minimum
Breakdown
Voltage
(BVCEO)
Typical
Current Transfer
Ratio
(%)
Maximum
Saturation
Voltage
(V)
Input
Control
Current
(mA)
Minimum
Isolation
Voltage
(VRMS)
Package
Type
CPC1001N 30 330 0.3 0.2 1500 10
4-Pin SOP
10
• LINEAR OPTOCOUPLERS
Two fundamental
operating configurations:
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
26 For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
See IXYS IC Application Note AN-500
“Depletion-Mode Power MOSFETs and Applications”
for descriptions and analyses of
the following applications
Features:
• Normally closed depletion mode devices offer low RDS(on) at cold temperatures
• High input impedance
• Low input capacitance
• Fast switching speeds
• Low input and output leakage
Applications:
• Power fail switches
• Discrete normally closed relays
• Constant current, high brightness LED drivers
• High voltage pre-regulators
• Power inverters
• Power supplies
• Depletion mode MOSFETs are normally closed
• Ideal for security applications
• LED drivers
SOT-223
SOT-89
SOT-23
• N-CHANNEL DEPLETION MODE MOSFETS
Part Number V(BR)DSX
(V)
ID
Min (mA)
RDS(on)
Max (W)
VGS(off)
Min (V)
VGS(off)
Max (V)
Package Type Features & Comments
CPC3701 60 600 1 −1.4 −3.1 SOT-89
CPC3703 250 360 4 −1.6 −3.9 SOT-89
CPC3708 350 130 14 −2 −3.6 SOT-89, SOT-223
CPC3710 250 220 10 −1.6 −3.9 SOT-89
CPC3714 350 240 14 −1.6 −3.9 SOT-89
CPC3720 350 130 22 −1.6 −3.9 SOT-89
CPC3730 350 140 35 −1.6 −3.9 SOT-89
CPC3902 250 400 2.5 −1.4 −3.1 SOT-223
CPC3909 400 300 6 −1.4 −3.1 SOT-89, SOT-223
CPC3960 600 100 44 −1.4 −3.1 SOT-223
CPC3980 800 100 45 −1.4 −3.1 SOT-223
CPC3982 800 20 380 −1.4 −3.1 SOT-23 Very small package
CPC5602 350 130 14 −2 −3.6 SOT-223 Designed for use with LITELINK applications
CPC5603 415 130 14 −2 −3.6 SOT-223 Designed for use with LITELINK applications
MOSFETS
MOSFETs
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 27
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
N-Channel Depletion Mode MOSFET as Pre-Regulator
Voltage
Regulator VDC
VAC
-
+
-
+
FDA217
V1
5V
R1
PV
PV
CPC3980
CPC3980
R2
V2
220VAC
1
2
3
4
8
7
6
5
Controller
I/O Pin
FDA217 (see page 19) used with CPC3980 MOSFETs
to create Normally Closed Solid State Relay
+HVIN
Q1
CPC3708
C1
1µF
VIN
GND
VOUT
C2
1µF
RL
5kΩ
IN OUT
+HVIN (V)
VOUT (V) and VIN (V)
0 30 60 90 120 150 180 210 240 270 300
0
2
4
6
8
10
IOUT (mA)
0
0.2
0.4
0.6
0.8
1.0
1.2
VIN
VOUT
IOUT
5V Regulator
High Voltage Off-line Linear Voltage Regulator
Time (ms)
VOUT (V)
012345678910
0
100
200
300
400
500
600
VOUT
V
IN
(V)
0
10
20
30
40
50
60
VIN
+HV
Q1
CPC3980
D
S
R1
17kΩ
C1
1nF
ID
VOUT
R2
25kΩ
Q2
IXTP02N120P
VIN
G
High Voltage Ramp Generator with Depletion-Mode and Enhancement-Mode N-Channel MOSFETs
MOSFETs
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
28 For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
HIGH SPEED DIGITAL OPTICAL ISOLATORS
LED
LED
1
2
3
4
8
7
6
5
VDD
OUT1
OUT2
GND
ANO1
CAT1
CAT2
ANO2
• SINGLE-CHANNEL EACH DIRECTION DIGITAL OPTICAL ISOLATOR: CPC5001
• DUAL HIGH SPEED DIGITAL OPTICAL ISOLATOR: CPC5002
Features:
• Isolates one signal in each direction
• Operates from 2.7V to 5.5V
• Buffered inputs - no external LED drive required
• Hysteresis at inputs for noise rejection
• Slew-limited drivers reduce EMI
• 3750VRMS galvanic isolation from input to output
• Power down to Hi-Z does not load outputs
• 5 Mbd data rate
Applications:
• Isolated signal monitoring and control
• Power-over-Ethernet, POE
• Power supply high-side interface
• Logic level translation
• Microprocessor system interface
• Inter integrated circuit (I2C) interface
• Serial peripheral interface
• Full duplex communication
• Isolated line receiver
• Isolated data acquisition systems
A
GND
A
B
GNDB
V
DDA
A
VDDA
CHANNEL2
VDDB
LED
INB2
VDDA
OUT
A2
A
VDDA
LED
INA1
VDDB
OUTB1
B
B
V
DDB
VDDB
CHANNEL1
1
2
3
4
8
7
6
5
CPC5001
CPC5002
• Logic level translation for levels as low as 2.7V or as high as 5.5V
• Passes DC signals - no refresh clock needed
Features:
• Dual optics isolate two signals
• 10 Mbd data rate
• Operates over 2.7V < VDD < 5.5V
• Power down to Hi-Z does not load outputs
• Low-power CMOS reduces supply current
• LED drive current only 1.5mA
• High speed: 10 Mbd typical
Applications:
• Isolated line receiver
• Ground loop elimination
• ADC/DAC digital noise isolation
• I2C bus isolation
• 3750VRMS galvanic isolation from input to output
• Passes DC signals - no refresh clock needed
High Speed Digital Optical Isolators
éfi % ‘ AlinelluuTechno‘ogv
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 29
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
High Speed Digital Optical Isolators
See Technical Brief TB-101
“Optically Isolating an I2C Interface”
• BIDIRECTIONAL, OPTICALLY ISOLATED I
²
C BUS REPEATERS: CPC5902 & CPC5904
Applications:
• Isolated Signal Monitoring and Control
• Power-over-Ethernet
• Power Supply High Side Interface
• I2C Bus Length Extenders
• I2C Logic Level Translation
Features:
• Bidirectionally buffers both I2C signals
• Extends and isolates I2C interfaces
• Supports I2C clock stretching
• No internal clock - low EM & RF generation
• Operates on 2.7V to 5.5V
• Supports DC logic level buffering without refresh
• Glitch-free operation
• Power down to Hi-Z does not load I2C bus
• Slew-limited drivers reduce EMI
• Immune to external EMI & RF emissions
• High voltage isolation
CPC5902 and CPC5904 are dual, optically isolated, bidirectional logic-bus repeaters. They galvanically isolate two open-drain logic signals, and provide a galvanic
isolation of 3750VRMS. When the two sides’ supply voltages are configured with different voltages, the CPC5902 and CPC5904 also function as logic level translators for
levels as low as 2.7V or as high as 5.5V. Unlike transformer or capacitive isolators, these isolated repeaters pass DC signals and do not need to be clocked periodically to
sustain the logic states. Buffered signals will always return to their proper value after a transient interruption on either side.
Optical
Isolation
Barrier
I2C
Master
I2C
Slave
I2C
Master
I2C
Slave
SCL_A
SDA_A
SCL_B
SDA_B
VDDA VDDA
VDDA VDDB
VDDB VDDB
GNDAGNDB
CPC5902 & CPC5904 Application Block Diagram
• CPC5902 Side B Fast-mode compliant (400kbit/s): VDDB > 4.5V
• CPC5904 Side B Fast-mode Plus compliant (1000kbit/s): VDDB > 2.7V
• Logic level translation for levels as low as 2.7V or as high as 5.5V
• Passes DC signals - no refresh clock needed
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
30 For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
High Speed Digital Optical Isolators
Applications:
• Power-over-Ethernet (POE)
• I2C bus length extender
• Isolated control and signal monitoring
• Power supply high-side interface
• I2C logic level translation
• OPTICALLY ISOLATED I
²
C BUS REPEATER: CPC5903
CPC5903
Optical
Isolation
Barrier
I2C
Master
I2C
Slave
I2C
Slave
I2C
Slave
SCL_A
SDA_A
SCL_B
SDA_B
VDDA VDDA
VDDA VDDB
VDDB VDDB
GNDAGNDB
• CPC5903 bidirectionally buffers data signal, unidirectionally buffers clock signal
• Logic level translation for levels as low as 2.7V or as high as 5.5V
• Passes DC signals - no refresh clock needed - no clock noise generated
See Technical Brief TB-101
“Optically Isolating an I2C Interface”
VDDA
VDDB
VDDA
B
VDDB
OB
LED
VDDA
IA
VDDA
A
VDDB
B
A
GNDA
A
VDDA
LED
VDDA
IOA
VDDB
QD
CLR
B
VDDB
LED
VDDB
IOB
B
GNDB
1
2
3
4 5
6
7
8
3750Vrms Optical Isolation
CPC5903 Application Block Diagram
The CPC5903 is a dual, optically isolated, logic-bus repeater. It isolates two open-drain logic signals while providing 3750VRMS of galvanic isolation. When the two sides are
powered by different supply voltages, it also functions as a logic level translator for levels as low as 2.7V or as high as 5.5V. Because the CPC5903 provides an isolated
bidirectional buffer for the I2C data signal and a unidirectional buffer for the I2C clock signal, it is best suited for applications where clock stretching is not required. This
configuration also requires the I2C bus master to be on the Side A bus. Unlike transformer or capacitive isolators, optical isolation passes DC signals and does not require
continuous high frequency modulation to transmit clock and logic signals across the galvanic isolation barrier. The CPC5903 always returns the buffered signals to their
proper state after transient interruptions on either side.
CPC5903 Block Diagram
CPC5903 Features:
• Minimum I2C clock frequency: 500kHz
• Bidirectionally buffers SDA I2C signal
• Side A extends and isolates I2C interfaces
• Standard-mode and Fast-mode I2C
• Side B fast-mode compliant: VDDB > 4.5V
• No internal clock - low EM & RF generation
• Operates on 2.7V to 5.5V
• Voltage level translation
• Slew-limited drivers reduce EMI
• Power down to Hi-Z does not load I2C bus
• 3750VRMS galvanic isolation
• Immune to external EMI & RF emissions
% IXYS Almeunu Tummy “HP
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 31
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
Digitally Programmable Capacitors
NON-VOLATILE DIGITALLY PROGRAMMABLE CAPACITORS
• WIDE CAPACITANCE RANGE, NON-VOLATILE, DIGITAL PROGRAMMABLE CAPACITOR: NCD2400M
The NCD2400M is a dedicated electronic calibrator for oscillators, with reliable performance at 105ºC as required by OCXO applications. This product can be
used in series or shunt configuration, to support a wide variety of tuning circuit topologies. Digitally controlled capacitance trimming information is communicated
via a 2-wire (I2C compatible) interface. The calibration value can be stored in the internal, re-programmable, non-volatile memory.
APPLICATIONS: • VCXOs • Crystal oscillators • Tunable RF stages • RFID tags • Industrial wireless control • Capacitor sensor trimming
DFN-EP package: 2mm x 2mm
SDA
SCL
VDD
DIGITAL
INTERFACE
AND
MEMORY
GND
CP
CN
V+
V+
V+ C0
Features:
• Series and shunt configurations supported:
Cshunt = 12.5pF to 194pF (15.6:1 tuning ratio) in discrete 355fF steps
Cseries = 1.7pF to 194pF in discrete 376fF steps
• 512-state digital programmable capacitor
• Operating frequency range of DC to 150MHz
• Operation at 105ºC
• 2-wire (I2C compatible) serial interface
• EEPROM non-volatile memory
• Wide power supply range (2.5V to 5.5V)
• 2mm x 2mm x 0.65mm 6-pin DFN package, MSL 1
Features:
• Capacitance range 6.6pF to 37.553pF
• 1024 programmable capacitance values
• Operating frequency range 200kHz to 250MHz
• Very small CDAC3 capacitance step size: 63fF
• Device size: 2mm x 2mm (DFN-6), 2.9mm x 2.8mm (TSOT-6)
• NON-VOLATILE DIGITAL PROGRAMMABLE CAPACITOR: NCD2100
The NCD2100 is an EEPROM-based digitally programmable variable capacitor that provides
capacitive offset trimming for capacitance sensitive circuits. Programming the non-volatile
EEPROM register value or implementing on demand capacitance value changes are easily
accomplished by means of the simple two-wire serial bus. To ensure interoperability over a
broad array of design environments, the device is rated for operation with supply voltages of
2.5V to 5.5V across the temperature range of −40ºC to +85ºC.
DFN-EP package: 2mm x 2mm TSOT package: 2.8mm x 2.9mm
DA
CLK
PV
VDD
X1
DIGITAL
INTERFACE
V
SS
CDAC1
CDAC2
CDAC3
C0
a:
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
32 For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
High Voltage LED Drivers
HIGH VOLTAGE LED DRIVERS
• CPC9909: High Efficiency, High Brightness Mains-Powered LED Driver
Features:
• >90% efficiency
• Stable operation at >50% duty cycle
• Regulated LED current
• Resistor-programmable minimum off-time
• Drives external power MOSFET, enabling high LED output current applications
• Buck or boost configuration
• 8V to 550V input voltage range
• Linear or PWM brightness control inputs
• Drives multiple LEDs in series/parallel
Applications:
• Flat-Panel Display RGB Backlighting
• Signage and Decorative LED Lighting
• DC/DC or AC/DC LED Driver Applications
CPC9909
Voltage
Regulator
Voltage
Reference
QTRIG
Minimum Off-Time
One Shot
S
R
Q
-
+
-
+
V
DD
V
IN
LD
PWMD
GND
CS
GATE
8 - 550V
V
DD
R
T
R
T
R
T
R
SENSE
Q1
D1
L1
Buck Configuration
CVDD
CPC9909 Application Diagram
8-Pin SOIC
8-Pin SOIC-EP
fl ‘ AlinelluuTechno‘ogv
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 33
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
High Voltage LED Drivers
• MXHV9910: High Voltage, Mains-Powered LED Driver
Features:
• 8V to 450V input voltage range
• >90% efficiency
• Drives multiple LEDs in series/parallel combinations
• Regulated LED drive current
•Linear or PWM brightness control inputs
• Resistor-programmable oscillator frequency
• Signage, decorative LED lighting
• Flat-panel display RGB backlighting
• DC & AC/DC LED driver applications
Applications:
• Flat-Panel Display RGB Backlighting
• Signage and Decorative LED Lighting
• DC/DC or AC/DC LED Driver Applications
HB LEDs
350mA
D1
BYV26B
C1
0.1µF
400V
C2
22µF
400V
R1
402kΩ
L1
4.7mH
R3
0.56Ω
R2
51kΩ
RA1
5.0kΩ
C3
2.2µF
16V
C4
0.1µF
25V
AC
AC +
-
BR1
Fuse F2
2A
NTC1 MXHV9910
VIN
CS
GND
GATE
RT
LD
VDD
PWMD
IXTA8N50P
LD
Monitor
AC Input
90 - 265Vrms
MXHV9910 Application Diagram
8-Pin SOIC
8-Pin SOIC-EP
IQ Im IQ IQ
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
34 For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
Multifunction Products
DA B C
E F G
22
8-Pin Surface Mount
21
8-Pin Flatpack
20
8-Pin DIP
4
16-Pin Low-Profile SOIC
Features:
• 3750VRMS input-to-output isolation
• Multiple functionality in a single package
• Current limiting (part numbers with “L” suffix)
• Machine insertable, wave solderable
• TTL and CMOS compatible
Applications:
• Telecommunication/datacommunication
• Instrumentation
• I/O subsystems/electronic switching
• Medical equipment (patient/equipment isolation)
• Security
• Industrial controls
The OptoMOS line of Multifunction Products combines a number of discrete, optically isolated functions into a single package. These products mix and match solid state
relays, optocouplers, and Darlington transistors to create highly functional circuits in a single, small package. Multifunction devices allow designers to consolidate circuit
functions into a single device, thus freeing up valuable board space and reducing component count.
• GENERAL PURPOSE MULTIFUNCTION PRODUCTS
Part
Number
Style SSR Characteristics Optocoupler Characteristics Isolation
Voltage
(VRMS)
Package
Type
Features and Comments
Blocking
Voltage
(VP)
Load
Current
(mA)
On
Resistance
(W)
Input
Control
Current
(mA)
Breakdown
Voltage
(V)
Current
Transfer
Ratio
(%)
Saturation
Voltage
(V)
Input
Control
Current
(mA)
IAA110 B 350 100 35 5 20 33 0.5 6 3750 4 Two 1-Form-A relays, one optocoupler
IAB110 C 350 100 35 5 20 33 0.5 6 3750 4 One 1-Form-A relay, one 1-Form-B relay, one optocoupler
IAD110 A 350 100 35 5 20 33 0.5 6 3750 4 One 1-Form-A relay, two optocouplers
IBB110 D 350 100 35 5 20 33 0.5 6 3750 4 Two 1-Form-B relays, one optocoupler
TS117 E 350 120 35 2 20 33 0.5 6 3750 20, 21, 22 One 1-Form-A relay, one optocoupler
TS117L E 350 120 35 2 20 33 0.5 6 3750 20, 21, 22 One current-limiting 1-Form-A relay, one optocoupler
TS118 F 350 120 35 5 20 33 0.5 6 3750 20, 21, 22 One 1-Form-B relay, one optocoupler
TS120 G 350 120 35 5 20 300 0.8 2 3750 20, 21, 22 One 1-Form-A relay, one Darlington optocoupler
TS190 E 400 150 22 5 20 33 0.5 6 3750 20, 21, 22 One 1-Form-A relay, one optocoupler
TS190L E 400 150 25 5 20 33 0.5 6 3750 21 One current-limiting 1-Form-A relay, one optocoupler
XS170 E 350 100 50 2 20 33 0.5 6 3750 20, 22 One 1-Form-A relay, one optocoupler
MULTIFUNCTION PRODUCTS: SSR/OPTOCOUPLERS
% ‘ AlinelluuTechna‘ogy
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 35
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
Multifunction Products
Features:
• 3750VRMS input-to-output isolation
• Multiple functionality in a single package
• Current limiting (part numbers with “L” suffix)
• Machine insertable, wave solderable
• TTL and CMOS compatible
Applications:
• Telecommunication/datacommunication
• Instrumentation
• I/O subsystems
• Electronic switching
• Medical equipment (patient/equipment isolation)
• Security
• Industrial controls
16-Pin SOIC
PV
Zener Protection
Unidirectional Opto-Input
Zener Protection
Bidirectional Opto-Input
PV
PV
No Zener Protection
Bidirectional Opto-Input
(1-Form-A) (1-Form-A)
(1-Form-A)
ITC117(L) ITC135 ITC137
Part
Number
Relay Parameters Optocoupler Parameters Isolation
Voltage
(VRMS)
Package
Type
Features
Blocking
Voltage
(VP)
Load
Current
(mA)
On
Resistance
(W)
Input Control
Current
(mA)
Breakdown
Voltage
(V)
Current
Transfer
Ratio (%)
Saturation
Voltage
(V)
Input Control
Current
(mA)
ITC117P 350 120 15 5 20 33 0.5 6 3750 16-pin SOIC Full-wave ringing detect
ITC117PL 350 120 20 5 20 33 0.5 6 3750 16-pin SOIC Full-wave ringing detect, current limiting
ITC135P 350 120 15 5 20 33 0.5 6 3750 16-pin SOIC Half-wave ringing detect
ITC137P 350 120 15 5 20 33 0.5 6 3750 16-pin SOIC Full-wave ringing detect
Multifunction devices allow designers to consolidate circuit functions into a single device, freeing up valuable board space and reducing component count. Designed
specifically for the telecommunications industry, the Integrated Telecom Circuit (ITC) series is well suited for voice telephony and modem applications, providing most of
the major functions required when designing DAA (Data Access Arrangement) or voice (FXO) line interface circuits. Available in a 16-pin SOIC package.
• TELECOMMUNICATIONS MULTIFUNCTION PRODUCTS
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
36 For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
Telecommunications Products
The 3kVRMS internal isolation barrier exceeds all worldwide regulatory requirements. The LITELINK application circuit is capable of surviving 6kV (10ms x 700ms) lightning
surge waveforms making it the most robust phone line interface IC on the market.
LITELINK offers the lowest operational phone line quiescent current. The device easily interfaces to commonly available standard single-ended or differential voice and
modem codecs on the market. Contact IXYS Integrated Circuits for information on codec reference designs that offer programmable AC termination impedance for global
applications. LITELINK complies with international PSTN agency requirements.
Applications:
• Computer telephony
•VoIP gateways
• PBXs
• Satellite set-top box
• V.92 modems
• Fax machines
•Voice mail systems
• Embedded modems
• Vending machines
• Automated banking
• Remote metering
•Surveillance
• Security systems
Features:
• Voice and data applications
•Modem DAA for speeds up to V.92
• Half-wave or full-wave ringing detection
• Worldwide telephone network compatibility
• Caller-ID reception
• Line side powered from telephone line
•3.3V to 5V power supply
• Easy interface with modem ICs and
voice codecs
• High power transmit option for
voice applications (>3dBm)
•Small 32-pin SOIC package
• LITELINK™ GALVANICALLY ISOLATED PHONE LINE INTERFACE
TIP
RING
Tx+
Tx-
OH
RING
MODE
RING2
Rx+
Rx-
Ringing Detect Outputs
Transconductance
Stage
2-4 Wire Hybrid
AC/DC Termination
Hook Switch
TX
Gain
Tr i m
RX
Gain
Tr i m
Transmit
Diff.
Amplifier
Receive
Diff.
Amplifier
Transmit
Isolation
Amplifier
Receive
Isolation
Amplifier
Snoop
Amplifier
RX MUX
&
Ringing Det. C
SNOOP
C
SNOOP
R
SNOOP
R
SNOOP
Half Wave
Full Wave
Isolation Barrier
CPC5622
Part
Number
Isolation
Voltage
(VRMS)
Power
Supply
(V)
Caller ID Ringing Detect
CPC5622 3000 3.3 - 5 Continuous Half-wave & full-wave
CPC5621 3000 3.3 - 5 Selectable (CID=0) Full-wave (CID=1)
CPC5620 3000 3.3 - 5 Selectable (CID=0) Half-wave (CID=1)
32-Pin SOIC
• Industry’s only single-package phone line interface
• Ideal for both voice and data (V.22bis to V.90/V.92) applications in particularly dense circuit environments
• Internal optical isolation barrier eliminates high-cost transformer or capacitive isolation circuits
• Saves cost through reduced passive component count and smaller printed circuit board space
TELECOMMUNICATIONS PRODUCTS
fl ‘ AlinelluuTechno‘ogv
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 37
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
Telecommunications Products
+
-
OH
RING
RING2
TX+
RX+
TX-
RX-
3.3 or 5V
BR-
BR-
BR-
TIP
RING
U1
LITELINK
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
VDD
TXSM
TX-
TX+
TX
GND
RX-
RX+
SNP+
SNP-
RXF
RX
MODE
OH
RING
RING2
REFL
TXF
ZTX
ZNT
TXSL
BR-
NTS
GAT
NTF
DCS1
DCS2
ZDC
BR-
RPB
RXS
VDDL BR-
BR-
A
A
A
BR- BR-
BR-
BR-
BR-
CPC5622
LITELINK: Resistive Termination Application Circuit Schematic
LITELINK can be used with telephone networks worldwide. Some public telephone networks, notably in North America and Japan require a resistive line termination. Other
telephone networks, such as in Europe, China and elsewhere, require a reactive line termination.
The application circuit shown here is typical of an application requiring a resistive termination. An example of a reactive-termination application is available in the data
sheets at our web site.
LITELINK III Resources available at our web site:
LITELINK III Evaluation Board
CPC5622-EVAL Evaluation Board Users Guide
CPC5622-EVAL Evaluation Board Design Files
u—u u—u u—u
IXYS Integrated Circuits − 78 Cherry Hill Drive − Beverly, MA USA 01915 − https://www.ixysic.com
38 For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
Telecommunications Products
Part
Number
Minimum
1500V/ms
dV/dt
Switch Pairs Zero-Cross
Switching
Protection Features Logic
States
Package
Type
#
Switches Break Ringing
Line
Test
Test
In
Ringing
Test
Current
Limit
Diode
Bridge
Protection
SCR
Minimum Hold
Current (mA)
CPC7695BC •10 • • • • • • • • • 110 9 SOIC-28
CPC7695ZC •10 • • • • • • • • • 110 9 SOIC-20
Features:
• Monolithic IC reliability
• Impulse noise reduction
• Low, matched on-resistance
• Built-in ringing zero-cross switching
• Small surface mount SOIC packages
• Ultra-low power consumption of <10.5mW
• Robust power-cross and lightning surge performance
• Current limiting, thermal shutdown, and SLIC protection
• LINE CARD ACCESS SWITCH (LCAS)
Applications:
• PBX systems
• VoIP gateways
• Channel banks
• Pair gain systems
• Central offices (CO)
• Fiber in the loop (FITL)
• Hybrid fiber coax (HFC)
• Digital loop carriers (DLC)
• Digitally added main line (DAML)
CPC7695
Break
TIP
RING
SLIC Codec PCM
Highway
SCR
and
Trip
Circuit
10 Switch - Ringing/Break
+ Line Test
+ Test-In
+ Ringing Test
Line
Test
Line
Test Ringing
Test
Ringing
Test Return
Break
Ringing
Access
Ringing
Return Test
In
Test
In
IXYS Almellnu Tummy 16er so? Reslslors
+1 978 524 6700, +1 978 524 4700 − Customer Service +1 978 524 6768, +1 978 524 4900 39
For data sheets, go to: https://www.ixysic.com/Products/ProdList.htm
Voltage Monitoring & Sensing IC
VOLTAGE MONITORING & SENSING IC
CPC5712
• Special-purpose “Voltage Monitor with Detectors” integrated circuit used in high voltage telephony applications
• Derives two voltage level detects, polarity information, and a scaled, linear representation of the phone line voltages
• Non-telephony applications include instrumentation and industrial controls; virtually undetectable in use
Features:
• 2 independent, programmable level-detectors with programmable hysteresis
• Fixed-level polarity detector with hysteresis
• Differential linear output
• Excellent common-mode rejection ratio (CMRR)
• Worldwide telephone network compatibility
• Minimum external components
• High differential input impedance, very low common-mode input impedance
• Fixed gain, 3V to 5.5V operation
• Low power consumption
• CMOS logic level output (TTL compatible)
Applications:
• VoIP gateways, IP-PBX, xDSL
• TIP/RING monitoring: polarity detection for caller ID, enhanced 911,
line-in-use, battery detection, PSTN check
16-Pin SOP
16-Pin SOP
Resistors set the Voltage Level Detect Thresholds
CPC5712 Application Circuit
DET1
DET2
POLARITY
+
-
IN+
IN-
OUT+
TIP
RING OUT -
OUT+
VCC
10 1312119
1
14
7
8
4
5
6
3
2
R1 R5R4R3R2
VREF VL1 VH1 VL2 VH2
G = 5
CPC5712
V+
Voltage Level Detect 2
Voltage Level Detect 1
Polarity Output
+ Analog Output
− Analog Output
(4)
10M
1%
1206
GND
1516
806K
1%
26.7K
1%
137K
1%
26.7K
1%
61.9K
1%
17.8K
1%
0.1µF
IXYS Integrated Circuits
Copyright © May 10, 2021 - Littelfuse, Inc. - All rights reserved.
https://www.ixysic.com
For information on technical or sales support or our authorized distributors:
https://www.littelfuse.com/contactus.aspx
