ESD12VD5-TP | ||
|---|---|---|
Digi-Key Part Number | ESD12VD5-TPMSTR-ND - Tape & Reel (TR) ESD12VD5-TPMSCT-ND - Cut Tape (CT) ESD12VD5-TPMSDKR-ND - Digi-Reel® | |
Manufacturer | ||
Manufacturer Product Number | ESD12VD5-TP | |
Description | TVS DIODE 12VWM 25VC SOD523 | |
Manufacturer Standard Lead Time | 10 Weeks | |
Detailed Description | 25V Clamp 9.6A (8/20µs) Ipp Tvs Diode Surface Mount SOD-523 | |
Customer Reference | ||
Datasheet | Datasheet | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | - | |
Package | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Product Status | Active | |
Type | Zener | |
Unidirectional Channels | 1 | |
Voltage - Reverse Standoff (Typ) | 12V (Max) | |
Voltage - Breakdown (Min) | 14.1V | |
Voltage - Clamping (Max) @ Ipp | 25V | |
Current - Peak Pulse (10/1000µs) | 9.6A (8/20µs) | |
Power - Peak Pulse | 240W | |
Power Line Protection | No | |
Applications | General Purpose | |
Capacitance @ Frequency | 55pF @ 1MHz | |
Operating Temperature | -55°C ~ 150°C (TJ) | |
Mounting Type | Surface Mount | |
Package / Case | SC-79, SOD-523 | |
Supplier Device Package | ||
Base Product Number |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | ESD(3V3-12V)D5 |
| Product Training Modules | |
| Video File | Micro Commercial Components Corporate Video |
| Environmental Information | |
| Featured Product | Miniature ESD Protection Devices |
| PCN Design/Specification | Halogen by Pkg Type 02/Sep/2023 |
| PCN Packaging | SOD-523 Reel Qty 23/Feb/2012 |
| Product Drawings | SOD-523 Package Top |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8541.10.0080 |
