B39162B3520U410 Datasheet by Qualcomm (RF front-end (RFFE) filters)

Data Sheet EPCOS
SAW Components
Data Sheet B3520
2Dec 17, 2004
SAW Components B3520
1575,42 MHzLow Loss Filter for Automotive Telematics
Data Sheet
Ceramic package DCC6C
Features
■RF low-loss filter for GPS application
■Package for Surface Mounted Technology
(SMT)
■Hermetically sealed ceramic package
■No matching network required for operation
at 50 Ω
■Extended temperature range for
automotive application
Terminals
■Ni, gold plated
Dimensions in mm, approx. weight 0,1 g
Pin configuration
2 Input
5 Output
1,3,4,6 Ground
Electrostatic Sensitive Device (ESD)
Type Ordering code Marking and Package
according to
Packing
according to
B3520 B39162-B3520-U410 C61157-A7-A56 F61074-V8070-Z000
Maximum ratings
Operable temperature range
T
A–40/+105 ˚C
Storage temperature range
T
stg –40/+105 ˚C
DC voltage
V
DC 0V
Source power
P
S0 dBm source impedance 50 Ω
3Dec 17, 2004
SAW Components B3520
1575,42 MHzLow Loss Filter for Automotive Telematics
Data Sheet
Characteristics
Reference temperature:
T
A= -40 ... +85 ˚C
Terminating source impedance:
Z
S=50Ω
Terminating load impedance:
Z
L=50Ω
min. typ. max.
Center frequency
f
c— 1575,42 — MHz
Maximum insertion attenuation
1574,22 ...1576,62 MHz αmax — 1,3 1,8 dB
Amplitude ripple (p-p) ∆α
1574,22 ...1576,62 MHz — 0,1 1,0 dB
Relative attenuation (relative to αmax)αrel
100,00 ...1450,00 MHz 40 44 — dB
1450,00 ...1520,00 MHz 30 34 — dB
1640,00 ...1710,00 MHz 25 30 — dB
1710,00 ...1750,00 MHz 35 43 — dB
1750,00 ...1910,00 MHz 42 44 — dB
1910,00 ...2000,00 MHz 40 45 — dB
Temperature coefficient of frequency
TC
f— -30 — ppm/K
4Dec 17, 2004
SAW Components B3520
1575,42 MHzLow Loss Filter for Automotive Telematics
Data Sheet
Characteristics
Reference temperature:
T
A= -40 ... +105 ˚C
Terminating source impedance:
Z
S=50Ω
Terminating load impedance:
Z
L=50Ω
min. typ. max.
Center frequency
f
c— 1575,42 — MHz
Maximum insertion attenuation
1574,22 ...1576,62 MHz αmax — 1,3 2,0 dB
Amplitude ripple (p-p) ∆α
1574,22 ...1576,62 MHz — 0,1 1,0 dB
Relative attenuation (relative to αmax)αrel
100,00 ...1450,00 MHz 40 44 — dB
1450,00 ...1520,00 MHz 30 34 — dB
1640,00 ...1710,00 MHz 25 30 — dB
1710,00 ...1750,00 MHz 35 43 — dB
1750,00 ...1910,00 MHz 42 44 — dB
1910,00 ...2000,00 MHz 40 45 — dB
Temperature coefficient of frequency
TC
f— -30 — ppm/K
a [dB] 35 1520 1540 1560 1580 1600 1620 1640 —— 1 [MHz] 55- 65 1200 1300 1400 1500 1600 1700 1800 1900 4— 1 [MHZ]
5Dec 17, 2004
SAW Components B3520
1575,42 MHzLow Loss Filter for Automotive Telematics
Data Sheet
Transfer function
Transfer function (wideband)
6Dec 17, 2004
SAW Components B3520
1575,42 MHzLow Loss Filter for Automotive Telematics
Data Sheet
