Name: 45214-220230
Brand: 3M
SKU: 3M15576TR-ND
Price: 951.43 INR
Availability: InStock

Image shown is a representation only. Exact specifications should be obtained from the product data sheet.

45214-220230
DigiKey Part Number	3M15576TR-ND - Tape & Reel (TR) 3M15576CT-ND - Cut Tape (CT) 3M15576DKR-ND - Digi-Reel®
Manufacturer	3M
Manufacturer Product Number	45214-220230
Description	CONN HEADER SMD 14POS 1.27MM
Manufacturer Standard Lead Time	8 Weeks
Customer Reference
Detailed Description	Connector Header Surface Mount 14 position 0.050" (1.27mm)
Datasheet	Datasheet
EDA/CAD Models	45214-220230 Models

Product Attributes

Filter Similar Products

Show Empty Attributes

Category Connectors, Interconnects Rectangular Connectors Headers, Male Pins	Fastening Type Latch Lock/Eject Hooks, Short
Mfr 3M	Insulation Height 0.222" (5.65mm)
Series 452	Contact Shape Square
Packaging Tape & Reel (TR) Cut Tape (CT) Digi-Reel®	Contact Finish - Mating Gold
Part Status Active	Contact Finish Thickness - Mating 30.0µin (0.76µm)
Connector Type Header	Contact Finish - Post Tin
Contact Type Male Pin	Contact Material Copper Alloy
Pitch - Mating 0.050" (1.27mm)	Insulation Material Liquid Crystal Polymer (LCP)
Number of Positions 14	Features Keying Slot, Pick and Place
Number of Rows 2	Operating Temperature -65°C ~ 125°C
Row Spacing - Mating 0.050" (1.27mm)	Material Flammability Rating UL94 V-0
Number of Positions Loaded All	Current Rating (Amps) 1A
Style Board to Cable/Wire	Voltage Rating 125V
Shrouding Shrouded - 4 Wall	Mated Stacking Heights 5.84mm, 6.60mm, 7.21mm, 8.13mm
Mounting Type Surface Mount	Contact Finish Thickness - Post 200.0µin (5.08µm)
Termination Solder	Base Product Number 45214
