7814G-1-023E | ||
|---|---|---|
Digi-Key Part Number | 7814G-023ETR-ND - Tape & Reel (TR) 7814G-023ECT-ND - Cut Tape (CT) 7814G-023EDKR-ND - Digi-Reel® | |
Manufacturer | ||
Manufacturer Product Number | 7814G-1-023E | |
Description | SWITCH ROTARY DIP SPDT 100MA 16V | |
Manufacturer Standard Lead Time | 10 Weeks | |
Detailed Description | Dip Switch SPDT 2 Position Surface Mount Rotary for Tool Actuator 100mA 16VAC/DC | |
| Customer Reference | ||
| Datasheet | Datasheet | |
Product Attributes
Type | Description | Select |
|---|---|---|
Category | ||
Mfr | Bourns Inc. | |
Series | ||
Package | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Product Status | Active | |
Circuit | SPDT | |
Number of Positions | 2 | |
Current Rating (Amps) | 100mA | |
Voltage Rating | 16VAC/DC | |
Actuator Type | Rotary for Tool | |
Actuator Level | Flush, Recessed | |
Contact Material | - | |
Contact Finish | - | |
Height Above Board | 0.100" (2.54mm) | |
Mounting Type | Surface Mount | |
Termination Style | Gull Wing | |
Pitch | - | |
Washable | No | |
Features | - | |
Operating Temperature | -55°C ~ 125°C | |
Body Material | - | |
Length | 0.177" (4.50mm) | |
Mechanical Life | 2,000 Cycles | |
Electrical Life | - | |
Base Product Number |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | 7814 Rotary Switch |
| Environmental Information | |
| CAD Models | |
| HTML Datasheet | 7814 Rotary Switch |
| EDA Models | 7814G-1-023E by Ultra Librarian |
| Product Drawings |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8536.50.9065 |
| California Prop 65 |  Warning Information |
144 In Stock
All prices are in INR
Cut Tape (CT) & Digi-Reel®
| Qty | Unit Price | Ext Price |
|---|---|---|
| 1 | ₹138.64000 | ₹138.64 |
| 10 | ₹134.49200 | ₹1,344.92 |
| 25 | ₹122.30520 | ₹3,057.63 |
| 100 | ₹106.25730 | ₹10,625.73 |
| 250 | ₹96.29324 | ₹24,073.31 |
Tape & Reel (TR)
| Qty | Unit Price | Ext Price |
|---|---|---|
| 500 | ₹89.65330 | ₹44,826.65 |
| 1,000 | ₹83.01170 | ₹83,011.70 |
| 2,500 | ₹75.26394 | ₹1,88,159.85 |
| 5,000 | ₹69.72983 | ₹3,48,649.15 |
| 12,500 | ₹66.40936 | ₹8,30,117.00 |
Manufacturers Standard Package
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | 7814G-023EDKR 2266-7814G-1-023E 7814G-001-023E 7814G-023ETR 7814G-023ECT 7814G1023E |
| Standard Package | 500 |
