TL3315NF100Q | ||
|---|---|---|
Digi-Key Part Number | EG4620TR-ND - Tape & Reel (TR) EG4620CT-ND - Cut Tape (CT) EG4620DKR-ND - Digi-Reel® | |
Manufacturer | ||
Manufacturer Product Number | TL3315NF100Q | |
Description | SWITCH TACTILE SPST-NO 0.05A 15V | |
Detailed Description | Tactile Switch SPST-NO Top Actuated Surface Mount | |
Customer Reference | ||
Datasheet | Datasheet | |
EDA/CAD Models | TL3315NF100Q Models | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | ||
Package | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Product Status | Active | |
Circuit | SPST-NO | |
Switch Function | Off-Mom | |
Contact Rating @ Voltage | 0.05A @ 15VDC | |
Actuator Type | Snap Dome | |
Mounting Type | ||
Actuator Height off PCB, Vertical | 0.55mm | |
Actuator Length, Right Angle | - | |
Actuator Orientation | Top Actuated | |
Termination Style | Gull Wing | |
Outline | 4.50mm x 4.50mm | |
Illumination | Non-Illuminated | |
Illumination Type, Color | - | |
Illumination Voltage (Nominal) | - | |
Operating Force | 100gf | |
Ingress Protection | - | |
Features | - | |
Operating Temperature | -20°C ~ 70°C | |
Actuator Material | - | |
Switch Travel | 0.20mm | |
Mechanical Life | 1,000,000 Cycles | |
Base Product Number |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | TL3315 Series Datasheet |
| Product Training Modules | Miniature Tactile Switches for Wearable and Hand-held Technology |
| Video File | How Does the Switch Attach to your Product What Electrical Ratings do You Need? What Switch do You Need? |
| Environmental Information | |
| Featured Product | TL3315 Series Ultra-Low-Profile Tactile Switch |
| CAD Models | TL3315NF100Q Models |
| HTML Datasheet | |
| EDA Models | TL3315NF100Q Models |
| Product Drawings |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8536.50.9031 |
Quantity
All prices are in INR
Cut Tape (CT) & Digi-Reel®
| Qty | Unit Price | Ext Price |
|---|---|---|
| 1 | ₹12.51000 | ₹12.51 |
| 10 | ₹12.00500 | ₹120.05 |
| 25 | ₹11.33840 | ₹283.46 |
| 100 | ₹10.31290 | ₹1,031.29 |
| 250 | ₹9.69760 | ₹2,424.40 |
| 500 | ₹8.87056 | ₹4,435.28 |
| 1,000 | ₹7.42660 | ₹7,426.60 |
| 2,500 | ₹7.22051 | ₹18,051.28 |
Tape & Reel (TR)
| Qty | Unit Price | Ext Price |
|---|---|---|
| 5,000 | ₹6.80783 | ₹34,039.15 |
| 10,000 | ₹6.39531 | ₹63,953.10 |
Manufacturers Standard Package
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | EG4620CT EG4620TR Q10122020 EG4620DKR |
| Standard Package | 5,000 |
