Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
VCUT0714A-HD1-GS08 | ||
|---|---|---|
Digi-Key Part Number | 751-1449-2-ND - Tape & Reel (TR) 751-1449-1-ND - Cut Tape (CT) 751-1449-6-ND - Digi-Reel® | |
Manufacturer | ||
Manufacturer Product Number | VCUT0714A-HD1-GS08 | |
Description | TVS DIODE 7VWM 14VWM LLP1006-2L | |
Manufacturer Standard Lead Time | 14 Weeks | |
Detailed Description | 17V, 30V Clamp 5A, 2A (8/20µs) Ipp Tvs Diode Surface Mount LLP1006-2L | |
Customer Reference | ||
Datasheet | Datasheet | |
EDA/CAD Models | VCUT0714A-HD1-GS08 Models | |
Product Attributes
Type | Description | Select All |
|---|---|---|
Category | ||
Mfr | ||
Series | - | |
Package | Tape & Reel (TR) Cut Tape (CT) Digi-Reel® | |
Product Status | Active | |
Type | Zener | |
Bidirectional Channels | 1 | |
Voltage - Reverse Standoff (Typ) | 7V, 14V | |
Voltage - Breakdown (Min) | 7.3V, 14.5V | |
Voltage - Clamping (Max) @ Ipp | 17V, 30V | |
Current - Peak Pulse (10/1000µs) | 5A, 2A (8/20µs) | |
Power - Peak Pulse | 54W, 63W | |
Power Line Protection | No | |
Applications | RS-485 | |
Capacitance @ Frequency | 8pF @ 1MHz | |
Operating Temperature | -40°C ~ 125°C (TJ) | |
Mounting Type | Surface Mount | |
Package / Case | SOD-882 | |
Supplier Device Package | ||
Base Product Number |
Documents & Media
| Resource Type | Link |
|---|---|
| Datasheets | VCUT0714A-HD1 |
| Product Training Modules | ESD Protection Family |
| PCN Assembly/Origin | Additional Backend Location 22/Mar/2016 |
| HTML Datasheet | VCUT0714A-HD1 |
| EDA Models | VCUT0714A-HD1-GS08 Models |
| Product Drawings | VCUT(05,07) Series Schematic |
Environmental & Export Classifications
| Attribute | Description |
|---|---|
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8541.10.0080 |
In-Stock: 1,69,546
Quantity
All prices are in INR
Cut Tape (CT) & Digi-Reel®
| Qty | Unit Price | Ext Price |
|---|---|---|
| 1 | ₹35.77000 | ₹35.77 |
| 10 | ₹25.28700 | ₹252.87 |
| 100 | ₹12.76810 | ₹1,276.81 |
| 500 | ₹10.41746 | ₹5,208.73 |
| 1,000 | ₹7.72909 | ₹7,729.09 |
| 2,000 | ₹6.50260 | ₹13,005.20 |
Tape & Reel (TR)
| Qty | Unit Price | Ext Price |
|---|---|---|
| 8,000 | ₹6.21687 | ₹49,734.96 |
| 16,000 | ₹5.37676 | ₹86,028.16 |
| 24,000 | ₹5.27593 | ₹1,26,622.32 |
| 56,000 | ₹4.36861 | ₹2,44,642.16 |
Manufacturers Standard Package
Additional Resources
| Attribute | Description |
|---|---|
| Other Names | 751-1449-2 751-1449-1 751-1449-6 VCUT0714AHD1GS08 |
| Standard Package | 8,000 |
