LV8413GPGEVB: 2 x DC Motor / 1 Stepper Driver

Summary

The LV8413GP is an H-bridge, 2-channel motor driver IC and is able to control 4 modes of forward, reverse, brake, and standby.

This IC housed in a miniature package is optimum for use in a stepping motor driving system for DSC or a camera module of cell phones.

Features

Saturation drive H-bridge : 2-channels
Built-in thermal protection circuit
Built-in low voltage malfunction prevention circuit
Incorporates a transistor for driving photosensors

Specifications

Manufacturer	onsemi
Category	Motor Control
Eval Board	Board not Stocked
Voltage In	2.5 ~ 5.5 V
Number of Motors and Type	2, DC Brush Motors 1, Stepper Motor, BiPolar
Power / Current Out	400 mA
Features	Brake Function Thermal Protection Under Voltage Protection, Brown-Out
Component Count + Extras	3 + 14
Application / Target Market	Cell Phones Digital Cameras
Design Author	ONSemiconductor
Main I.C. Base Part	LV8413GP
Date Created By Author	2011-06
Date Added To Library	2012-06
